A ready-to-deploy Jetson-based AI computing platform combining NVIDIA Jetson modules, Waveshare carrier board, NVMe storage, wireless connectivity, industrial-grade metal enclosure and 12V power supply.
Select the Jetson module based on your required AI performance, memory capacity and deployment requirements.
Entry-level AI edge computing
Higher-performance AI workloads
Advanced AI and robotics
High-performance edge AI
Available with Jetson Orin Nano 4GB/8GB and Jetson Orin NX 8GB/16GB module configurations.
Reliable carrier platform providing interfaces for storage, networking, USB, GPIO and other peripheral connectivity.
Rugged industrial-grade metal case designed to provide mechanical protection for the Jetson computing platform during deployment.
Pre-installed NVMe solid-state storage provides fast read/write performance for operating systems, applications and AI workloads.
Integrated wireless connectivity with Wi-Fi and Bluetooth support for networked edge applications and peripheral communication.
Includes a 12V 5A power supply suitable for powering the assembled Jetson platform.
Unlike an open development-board setup, this configuration is assembled inside an industrial-grade metal enclosure, making it more suitable for integration into robotics, automation and edge-computing systems.
Rigid metal construction | Protection for the Jetson module and carrier board
Improved mechanical durability | Suitable for embedded and industrial installations
Designed for long-term deployment environments
Selected NVIDIA Jetson Orin Nano / Orin NX module
Waveshare carrier board
Industrial-grade metal enclosure
NVMe SSD
Wi-Fi + Bluetooth wireless module
Antennas
Cooling solution
12V 5A power supply
Gigabit Ethernet connectivity
USB connectivity
GPIO / expansion interfaces
CSI camera interfaces supported by carrier board
Wireless network connectivity
| Specification | Jetson Orin Nano 4GB | Jetson Orin Nano 8GB | Jetson Orin NX 8GB | Jetson Orin NX 16GB |
|---|---|---|---|---|
| AI Performance | ||||
| Sparse INT8 Performance — Standard | Up to 20 TOPS | Up to 40 TOPS | Up to 70 TOPS | Up to 100 TOPS |
| Sparse INT8 Performance — MAXN_SUPER | Up to 34 TOPS | Up to 67 TOPS | Up to 117 TOPS | Up to 157 TOPS |
| Dense INT8 Performance — Standard | Up to 10 TOPS | Up to 20 TOPS | Up to 35 TOPS | Up to 50 TOPS |
| Dense INT8 Performance — MAXN_SUPER | Up to 17 TOPS | Up to 33 TOPS | Up to 58 TOPS | Up to 78 TOPS |
| GPU & CUDA | ||||
| GPU Architecture | NVIDIA Ampere GPU | |||
| CUDA Cores | 512 | 1024 | 1024 | 1024 |
| Tensor Cores | 16 | 32 | 32 | 32 |
| GPU Frequency — Standard | Up to 625 MHz | Up to 765 MHz | Up to 918 MHz | |
| GPU Frequency — MAXN_SUPER | Up to 1020 MHz | Up to 1173 MHz | ||
| FP32 Performance — Standard | 0.64 TFLOPs | 1.28 TFLOPs | 1.56 TFLOPs | 1.88 TFLOPs |
| FP32 Performance — MAXN_SUPER | 1.04 TFLOPs | 2.08 TFLOPs | 2.40 TFLOPs | 2.40 TFLOPs |
| FP16 Performance — Standard | 1.28 TFLOPs | 2.56 TFLOPs | 3.12 TFLOPs | 3.76 TFLOPs |
| FP16 Performance — MAXN_SUPER | 2.08 TFLOPs | 4.16 TFLOPs | 4.80 TFLOPs | 4.80 TFLOPs |
| CPU | ||||
| CPU | 6-core Arm Cortex-A78AE | 6-core Arm Cortex-A78AE | 8-core Arm Cortex-A78AE | |
| CPU Frequency — Standard | Up to 1.5 GHz | Up to 2.0 GHz | ||
| CPU Frequency — MAXN_SUPER | Up to 1.7 GHz | Up to 2.0 GHz | ||
| Memory | ||||
| LPDDR5 Memory | 4GB | 8GB | 8GB | 16GB |
| Memory Bus | 64-bit | 128-bit | 128-bit | |
| Memory Bandwidth — Standard | 34 GB/s | 68 GB/s | 102 GB/s | |
| Memory Bandwidth — MAXN_SUPER | 51 GB/s | 102 GB/s | 102 GB/s | |
| Video & Display | ||||
| Video Decode | H.265 / H.264 / VP9 / AV1 | H.265 / H.264 / VP9 / AV1 | ||
| Video Encode | 1080p30 via CPU software | H.265 / H.264 / AV1 | ||
| Maximum Display Resolution | 3840 × 2160 @ 30 Hz | 7680 × 4320 @ 30 Hz | ||
| High-Speed Interfaces | ||||
| PCIe | Up to PCIe Gen3 | Up to PCIe Gen4 | ||
| USB | Up to 3 × USB 3.2 + 3 × USB 2.0 | |||
| MIPI CSI-2 | 8 lanes | |||
| Gigabit Ethernet | 10/100/1000 Mbps | |||
| Power Modes | ||||
| Standard Power Modes | 7W / 10W | 7W / 15W | 10W / 15W / 20W | 10W / 15W / 25W |
| MAXN_SUPER Power Mode | 25W | 25W | 40W | 40W |
| Operating Temperature (TJ) | -25°C to 105°C | |||
| 24×7 Operating Lifetime | 5 Years | |||
Jetson platforms provide an extensive software ecosystem for developing and deploying accelerated AI applications at the edge.
Software stack for Jetson development, including system software, libraries and tools for accelerated AI applications.
Robotics development platform supporting simulation, perception, navigation and accelerated robotics workloads.
AI-powered video analytics platform for smart spaces, industrial monitoring and computer vision applications.
Designed for Jetson Orin NX / Nano with passive cooling
Exquisite manufacturing process, Fitting & Nice Looking
Easy to install to specific scenarios
| Document | Link |
|---|---|
| Jetson Orin Nano Datasheet | View Datasheet |
| Jetson Orin NX Datasheet | View Datasheet |
| Jetson Orin Nano / NX Flashing Guide | View Guide |
| Item | Quantity |
|---|---|
| Selected Jetson Orin Nano / Orin NX Module | 1 |
| Waveshare Carrier Board | 1 |
| Industrial-Grade Metal Enclosure | 1 |
| 240GB NVMe SSD | 1 |
| Wi-Fi + Bluetooth Module | 1 |
| Wireless Antennas | 2 |
| 12V 5A Power Supply | 1 |
