Have you ever needed to keep track of how many items pass down a conveyor belt, or wanted to build a smart trash bin that tells you when it is full? This project turns a standard Arduino Nano into an automated object counter using a simple infrared (IR) sensor. It tracks every object that passes by and even gives a visual hardware alert when the bin reaches its maximum capacity. Code for this project is available here.
The Hardware Setup
This build relies on three main components communicating with each other:
- IR Sensor: Connected to digital pin 2, this acts as our digital tripwire.
- I2C LCD Display: Operating on standard address 0x27, this screen displays the live count and system alerts.
- The Brains: An Arduino Nano reading the sensor and pushing visual updates to the screen.
Component Pinout Guide
Wire your components to the Arduino Nano using the following connections:
| Component | Component Pin | Arduino Nano Pin | Function |
|---|---|---|---|
| IR Sensor | VCC | 5V | Power supply |
| IR Sensor | GND | GND | Ground |
| IR Sensor | OUT / SIG | D2 | Digital signal (Tripwire) |
| I2C LCD | VCC | 5V | Power supply |
| I2C LCD | GND | GND | Ground |
| I2C LCD | SDA | A4 | I2C Data line |
| I2C LCD | SCL | A5 | I2C Clock line |
How It Works: Tracking Capacity
The core logic is built around a predefined "bin capacity" of 10 items. When the IR sensor detects an object, its signal drops to LOW. The Arduino registers this event, increments the total object count by one, and immediately updates the LCD to show the new count.
Once the recorded count hits that magic number of 10, the system goes into alert mode. The screen clears its standard tracking text and flashes a "!!! ALERT !!! BIN IS FULL" message.
Technical Highlights in the Code
State Change Detection
The code does not just blindly count whenever the sensor is blocked. It actively compares the current sensor state to the last known state. This ensures that if an object stops directly in front of the sensor, it only gets counted exactly once, preventing inflated false data.
Driverless I2C Communication
To keep the compiled memory footprint as light as possible, this code skips bulky third-party display libraries. Instead, it uses custom, bare-metal functions to send hexadecimal commands directly over the I2C bus to the display.
Hardware Visual Alarms
When the bin is full, the code takes the alert a step further than just text on a screen. It manipulates
the LCD's backlight variable, toggling between LCD_BACKLIGHT and
LCD_NOBACKLIGHT every 500 milliseconds to physically flash the screen and grab
your attention.
