Device System Support
 |
Raspberry Pi
Supports Raspbian, 10-points touch, driver free
Supports Ubuntu / Kali / WIN10 IoT, single point touch, driver free
Supports Retropie, driver free
Supports all versions of Raspberry Pi
Jetson Nano
Supports Ubuntu, single point touch, driver free
PC
Supports Windows 11 / 10 / 8.1 / 8 / 7, 10-points touch, driver free
Game Console
Xbox360, PS4, Switch...
|
Connection Examples
Working With Raspberry Pi 4B
Working With Raspberry Pi 3B+
Working With Raspberry Pi Zero 2 W
You need to prepare additional mini HDMI adapter and USB cable
Working With Jetson Nano
Working With PC
for reference only, the above controller boards or hosts are NOT included
IPS Display Panel
Excellent Display Performance With 178° Wide Viewing Angle
QLED Quantum Dot Technology
Wider Color Gamut
Color Gamut Of This QLED Display Is Up To: SRGB 94%, NTSC 94%
More Pure Chroma
Chroma Of QLED Increases 58.3%, Makes The Color More Pure, More Vivid
Longer Lifetime
Due To Its Inorganic Characteristic, The Color Life Of QLED Could Be Up To 60000 Hours Without Color Degradation
Capacitive 10-Point Touch
- up to 10-point touch, depending on the operating system
- up to 6H hardness toughened glass panel
- Optical Bonding, display well and dustproof
Supports DDC/CI Brightness Adjustment
Interface Introduction
Dimensions
Resources
Wiki: www.waveshare.com/wiki/10.4HP-CAPQLED
Package Contains:
Weight: 0.769 kg
- 10.4HP-CAPQLED ×1
- HDMI flat cable ~1m ×1
- USB-A to USB-C cable ~1m ×1
- Button board ×1
- Button board cable ×1
- USB to Type-C adapter (B) ×1
- USB to Type-C adapter (C) ×1
- HDMI to Micro HDMI adapter ×1
- HDMI adapter ×1
- Screws pack ×1
-
OPTIONS 5V 3A Type C Power supply ×1
Use left/right arrows to navigate the slideshow or swipe left/right if using a mobile device
{"id":9460996342077,"title":"10.4inch QLED Display","handle":"10-4inch-qled-display","description":"\u003cdiv align=\"center\"\u003e\n\u003cmeta charset=\"UTF-8\"\u003e\n\u003ch1 class=\"richTitle\" style=\"text-align: center;\"\u003e10.4″ QLED Touch Display\u003c\/h1\u003e\n\u003ch4 class=\"richDesc hilitBlock2 round1234\" style=\"text-align: center;\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003eHigh Resolution | Multi-Point Touch | Full Color\u003c\/span\u003e\u003c\/h4\u003e\n\u003cspan\u003e\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-1.jpg\"\u003e\n\u003ctable align=\"center\" width=\"90%\"\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eSize\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Dimension.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Dimension.png\"\u003e\u003cspan class=\"igValue\"\u003e10.4\"\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eResolution\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Resolution.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Resolution.png\"\u003e\u003cspan class=\"igValue\"\u003e1600×720\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eDisplay Port\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/HDMI.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/HDMI.png\"\u003e\u003cspan class=\"igValue\"\u003eHDMI\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eDisplay Panel\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/QLED.png\"\u003e\u003cspan class=\"igValue\"\u003eQLED Quantum Dot\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eViewing Angle\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Viewing_angle.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Viewing_angle.png\"\u003e\u003cspan class=\"igValue\"\u003e170°\u003c\/span\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Type\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Capacitive_touch.png\"\u003e\u003cspan class=\"igValue\"\u003eCapacitive\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Points\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Ten_touch.png\"\u003e\u003cspan class=\"igValue\"\u003e10-Point\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Type\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Type_C.png\"\u003eUSB Type-C\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Panel\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Tempered_panel.png\"\u003e\u003cspan class=\"igValue\"\u003eToughened Glass\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Panel Tech\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Full-Fit.png\"\u003e\u003cspan class=\"igValue\"\u003eOptical Bonding\u003c\/span\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eBrightness\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Backlight-1line.png\"\u003eSupports DCC\/CI\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eOSD Menu\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/OSD.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/OSD.png\"\u003e\u003cspan class=\"igValue\"\u003eBrightness\/Contrast\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eAudio Output1\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/3.5mm-Audio.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/3.5mm-Audio.png\"\u003e\u003cspan class=\"igValue\"\u003e3.5mm Jack\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eAudio Output2\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/4PIN.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/4PIN.png\"\u003e\u003cspan class=\"igValue\"\u003e4PIN Header\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eBrightness\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Brightness.png\"\u003e\u003cspan class=\"igValue\"\u003e600cd\/m²\u003c\/span\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003cdiv class=\"sep0px\"\u003e\u003cbr\u003e\u003c\/div\u003e\n\u003c\/div\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\" data-mce-style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\" data-mce-style=\"text-align: center;\"\u003eDevice System Support\u003c\/h2\u003e\n\u003cp\u003e\u003cbr\u003e\u003c\/p\u003e\n\u003ctable align=\"center\" style=\"width: 90%; margin: auto; border-collapse: collapse; border: none;\" data-mce-style=\"width: 90%; margin: auto; border-collapse: collapse; border: none;\"\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd style=\"border: none; vertical-align: top; text-align: center;\" data-mce-style=\"border: none; vertical-align: top; text-align: center;\"\u003e\u003cimg style=\"float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/DevSp-PI-JT-PC-GM.jpg\" data-mce-style=\"float: none;\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/DevSp-PI-JT-PC-GM.jpg\"\u003e\u003c\/td\u003e\n\u003ctd style=\"border: none; vertical-align: middle; text-align: center;\"\u003e\n\u003cp\u003eRaspberry Pi\u003c\/p\u003e\n\u003cdiv class=\"subBlock\"\u003eSupports Raspbian, 10-points touch, driver free\u003cbr\u003eSupports Ubuntu \/ Kali \/ WIN10 IoT, single point touch, driver free\u003cbr\u003eSupports Retropie, driver free\u003c\/div\u003e\n\u003cp class=\"noteBg\"\u003eSupports all versions of Raspberry Pi\u003c\/p\u003e\n\u003cdiv class=\"largerBlock\"\u003eJetson Nano\u003c\/div\u003e\n\u003cdiv class=\"subBlock\"\u003eSupports Ubuntu, single point touch, driver free\u003c\/div\u003e\n\u003cdiv class=\"largerBlock\"\u003ePC\u003c\/div\u003e\n\u003cdiv class=\"subBlock\"\u003eSupports Windows 11 \/ 10 \/ 8.1 \/ 8 \/ 7, 10-points touch, driver free\u003c\/div\u003e\n\u003cdiv class=\"largerBlock\"\u003eGame Console\u003c\/div\u003e\n\u003cdiv class=\"subBlock\"\u003eXbox360, PS4, Switch...\u003c\/div\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003cdiv style=\"text-align: center;\" class=\"mgnTB_p\" data-mce-style=\"text-align: center;\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\" data-mce-style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\"\u003eConnection Examples\u003c\/h2\u003e\n\u003ch4 style=\"text-align: center;\" class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 1);\"\u003eWorking With Raspberry Pi 4B\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-3.jpg\"\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003ch4 class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003eWorking With Raspberry Pi 3B+\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-5.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003ch4 class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 1);\"\u003eWorking With Raspberry Pi Zero 2 W\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-7.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003cp class=\"note\" style=\"text-align: left;\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003e\u003cem\u003eYou need to prepare additional mini HDMI adapter and USB cable\u003c\/em\u003e\u003c\/span\u003e\u003c\/p\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003ch4 class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 1);\"\u003eWorking With Jetson Nano\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-9.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003ch4 class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003eWorking With PC\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-13.jpg\"\u003e\n\u003cdiv\u003e\u003cbr\u003e\u003c\/div\u003e\n\u003cdiv class=\"msg msg_warning\"\u003e\u003cspan style=\"color: rgb(194, 0, 1);\"\u003e\u003cem\u003efor reference only, the above controller boards or hosts are NOT included\u003c\/em\u003e\u003c\/span\u003e\u003c\/div\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003eIPS Display Panel\u003c\/h2\u003e\n\u003cp class=\"richDesc\" style=\"text-align: center;\"\u003e\u003cstrong\u003eExcellent Display Performance With 178° Wide Viewing Angle\u003c\/strong\u003e\u003c\/p\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-15.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003eQLED Quantum Dot Technology\u003c\/h2\u003e\n\u003ch3 style=\"text-align: center;\" class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003eWider Color Gamut\u003c\/span\u003e\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\" class=\"richDesc subBlock\"\u003e\u003cstrong\u003eColor Gamut Of This QLED Display Is Up To: SRGB 94%, NTSC 94%\u003c\/strong\u003e\u003c\/p\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/15.6HP-CAPQLED\/QLED1.jpg\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richDesc\"\u003e \u003c\/h2\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richDesc\"\u003eMore Pure Chroma\u003c\/h2\u003e\n\u003cp class=\"richDesc subBlock\"\u003e\u003cstrong\u003eChroma Of QLED Increases 58.3%, Makes The Color More Pure, More Vivid\u003c\/strong\u003e\u003c\/p\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/7HP-CAPQLED\/QLED2.jpg\"\u003e\n\u003ch2 class=\"richDesc\"\u003e \u003c\/h2\u003e\n\u003ch2 class=\"richDesc\"\u003eLonger Lifetime\u003c\/h2\u003e\n\u003cp class=\"richDesc subBlock\"\u003e\u003cstrong\u003eDue To Its Inorganic Characteristic, The Color Life Of QLED Could Be Up To 60000 Hours Without Color Degradation\u003c\/strong\u003e\u003c\/p\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/7HP-CAPQLED\/QLED3.jpg\"\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\" class=\"pdT\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\"\u003e \u003c\/h2\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\"\u003eCapacitive 10-Point Touch\u003c\/h2\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-17.jpg\"\u003e\n\u003cdiv class=\"alignl bgGrey\"\u003e\n\u003col class=\"alignl\"\u003e\n\u003cli style=\"text-align: left;\"\u003eup to 10-point touch, depending on the operating system\u003c\/li\u003e\n\u003cli style=\"text-align: left;\"\u003eup to 6H hardness toughened glass panel\u003c\/li\u003e\n\u003cli style=\"text-align: left;\"\u003eOptical Bonding, display well and dustproof\u003c\/li\u003e\n\u003c\/ol\u003e\n\u003c\/div\u003e\n\u003c\/div\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\"\u003eSupports DDC\/CI Brightness Adjustment\u003c\/h2\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-18.gif\"\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003eInterface Introduction\u003c\/h2\u003e\n\u003cdiv\u003e\u003cbr\u003e\u003c\/div\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-19.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003c\/div\u003e\n\u003cdiv\u003e\n\u003ch2 style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003ch2 style=\"text-align: center;\"\u003eDimensions\u003c\/h2\u003e\n\u003cbr\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-size.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\u003c\/div\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003ch2 class=\"richTitle\"\u003e \u003c\/h2\u003e\n\u003ch2 class=\"richTitle\"\u003eResources\u003c\/h2\u003e\n\u003cp\u003e\u003cstrong\u003eWiki: \u003c\/strong\u003e\u003ca href=\"http:\/\/www.waveshare.com\/wiki\/10.4HP-CAPQLED\" target=\"_blank\"\u003ewww.waveshare.com\/wiki\/10.4HP-CAPQLED\u003c\/a\u003e\u003c\/p\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003ch2\u003e \u003c\/h2\u003e\n\u003ch2\u003ePackage Contains:\u003c\/h2\u003e\n\u003cp\u003e\u003cstrong\u003eWeight: \u003c\/strong\u003e\u003cspan\u003e0.769 kg\u003c\/span\u003e\u003c\/p\u003e\n\u003cdiv class=\"std\"\u003e\n\u003col\u003e\n\u003cli\u003e10.4HP-CAPQLED ×1\u003c\/li\u003e\n\u003cli\u003eHDMI flat cable ~1m ×1\u003c\/li\u003e\n\u003cli\u003eUSB-A to USB-C cable ~1m ×1\u003c\/li\u003e\n\u003cli\u003eButton board ×1\u003c\/li\u003e\n\u003cli\u003eButton board cable ×1\u003c\/li\u003e\n\u003cli\u003eUSB to Type-C adapter (B) ×1\u003c\/li\u003e\n\u003cli\u003eUSB to Type-C adapter (C) ×1\u003c\/li\u003e\n\u003cli\u003eHDMI to Micro HDMI adapter ×1\u003c\/li\u003e\n\u003cli\u003eHDMI adapter ×1\u003c\/li\u003e\n\u003cli\u003eScrews pack ×1\u003c\/li\u003e\n\u003cli\u003e\n\u003cspan class=\"noteBg\"\u003eOPTIONS\u003c\/span\u003e 5V 3A Type C Power supply ×1\u003c\/li\u003e\n\u003c\/ol\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-pack.jpg\"\u003e\n\u003c\/div\u003e","published_at":"2024-05-31T07:47:10+05:30","created_at":"2024-05-31T07:38:25+05:30","vendor":"Waveshare","type":"","tags":["10.1\"","10.1inch","1600","1600×720","24646","720","720p","capacitive","CAPQLED","DISP3","Display","ELC2","glass","hdmi","hdmi display","inch","OLED","pixels","QLED","quantum","Quantum Dot","quantum led","touch","toughened","WaveSH","Waveshare","WVSH"],"price":1099999,"price_min":1099999,"price_max":1099999,"available":true,"price_varies":false,"compare_at_price":1799999,"compare_at_price_min":1799999,"compare_at_price_max":1799999,"compare_at_price_varies":false,"variants":[{"id":48857674645821,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"ELC2122","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"10.4inch QLED Display","public_title":null,"options":["Default Title"],"price":1099999,"weight":2000,"compare_at_price":1799999,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-1_1.jpg?v=1717121530","\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-2_1.jpg?v=1717121537","\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-3_1.jpg?v=1717121537","\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-4_1.jpg?v=1717121537","\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-5_1.jpg?v=1717121537"],"featured_image":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-1_1.jpg?v=1717121530","options":["Title"],"media":[{"alt":null,"id":38571587109181,"position":1,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-1_1.jpg?v=1717121530"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-1_1.jpg?v=1717121530","width":800},{"alt":null,"id":38571587240253,"position":2,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-2_1.jpg?v=1717121537"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-2_1.jpg?v=1717121537","width":800},{"alt":null,"id":38571587207485,"position":3,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-3_1.jpg?v=1717121537"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-3_1.jpg?v=1717121537","width":800},{"alt":null,"id":38571587174717,"position":4,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-4_1.jpg?v=1717121537"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-4_1.jpg?v=1717121537","width":800},{"alt":null,"id":38571587141949,"position":5,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-5_1.jpg?v=1717121537"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/10.4hp-capqled-5_1.jpg?v=1717121537","width":800}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cdiv align=\"center\"\u003e\n\u003cmeta charset=\"UTF-8\"\u003e\n\u003ch1 class=\"richTitle\" style=\"text-align: center;\"\u003e10.4″ QLED Touch Display\u003c\/h1\u003e\n\u003ch4 class=\"richDesc hilitBlock2 round1234\" style=\"text-align: center;\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003eHigh Resolution | Multi-Point Touch | Full Color\u003c\/span\u003e\u003c\/h4\u003e\n\u003cspan\u003e\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-1.jpg\"\u003e\n\u003ctable align=\"center\" width=\"90%\"\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eSize\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Dimension.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Dimension.png\"\u003e\u003cspan class=\"igValue\"\u003e10.4\"\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eResolution\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Resolution.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Resolution.png\"\u003e\u003cspan class=\"igValue\"\u003e1600×720\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eDisplay Port\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/HDMI.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/HDMI.png\"\u003e\u003cspan class=\"igValue\"\u003eHDMI\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eDisplay Panel\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/QLED.png\"\u003e\u003cspan class=\"igValue\"\u003eQLED Quantum Dot\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eViewing Angle\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Viewing_angle.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Viewing_angle.png\"\u003e\u003cspan class=\"igValue\"\u003e170°\u003c\/span\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Type\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Capacitive_touch.png\"\u003e\u003cspan class=\"igValue\"\u003eCapacitive\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Points\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Ten_touch.png\"\u003e\u003cspan class=\"igValue\"\u003e10-Point\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Type\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Type_C.png\"\u003eUSB Type-C\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Panel\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Tempered_panel.png\"\u003e\u003cspan class=\"igValue\"\u003eToughened Glass\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eTouch Panel Tech\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Full-Fit.png\"\u003e\u003cspan class=\"igValue\"\u003eOptical Bonding\u003c\/span\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eBrightness\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Backlight-1line.png\"\u003eSupports DCC\/CI\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eOSD Menu\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/OSD.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/OSD.png\"\u003e\u003cspan class=\"igValue\"\u003eBrightness\/Contrast\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eAudio Output1\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/3.5mm-Audio.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/3.5mm-Audio.png\"\u003e\u003cspan class=\"igValue\"\u003e3.5mm Jack\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eAudio Output2\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/4PIN.png\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/4PIN.png\"\u003e\u003cspan class=\"igValue\"\u003e4PIN Header\u003c\/span\u003e\n\u003c\/td\u003e\n\u003ctd style=\"border: 0px; text-align: center; vertical-align: top;\"\u003e\n\u003cspan class=\"igKey\"\u003eBrightness\u003c\/span\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/250\/Brightness.png\"\u003e\u003cspan class=\"igValue\"\u003e600cd\/m²\u003c\/span\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003cdiv class=\"sep0px\"\u003e\u003cbr\u003e\u003c\/div\u003e\n\u003c\/div\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\" data-mce-style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\" data-mce-style=\"text-align: center;\"\u003eDevice System Support\u003c\/h2\u003e\n\u003cp\u003e\u003cbr\u003e\u003c\/p\u003e\n\u003ctable align=\"center\" style=\"width: 90%; margin: auto; border-collapse: collapse; border: none;\" data-mce-style=\"width: 90%; margin: auto; border-collapse: collapse; border: none;\"\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd style=\"border: none; vertical-align: top; text-align: center;\" data-mce-style=\"border: none; vertical-align: top; text-align: center;\"\u003e\u003cimg style=\"float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/DevSp-PI-JT-PC-GM.jpg\" data-mce-style=\"float: none;\" data-mce-src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/common\/DevSp-PI-JT-PC-GM.jpg\"\u003e\u003c\/td\u003e\n\u003ctd style=\"border: none; vertical-align: middle; text-align: center;\"\u003e\n\u003cp\u003eRaspberry Pi\u003c\/p\u003e\n\u003cdiv class=\"subBlock\"\u003eSupports Raspbian, 10-points touch, driver free\u003cbr\u003eSupports Ubuntu \/ Kali \/ WIN10 IoT, single point touch, driver free\u003cbr\u003eSupports Retropie, driver free\u003c\/div\u003e\n\u003cp class=\"noteBg\"\u003eSupports all versions of Raspberry Pi\u003c\/p\u003e\n\u003cdiv class=\"largerBlock\"\u003eJetson Nano\u003c\/div\u003e\n\u003cdiv class=\"subBlock\"\u003eSupports Ubuntu, single point touch, driver free\u003c\/div\u003e\n\u003cdiv class=\"largerBlock\"\u003ePC\u003c\/div\u003e\n\u003cdiv class=\"subBlock\"\u003eSupports Windows 11 \/ 10 \/ 8.1 \/ 8 \/ 7, 10-points touch, driver free\u003c\/div\u003e\n\u003cdiv class=\"largerBlock\"\u003eGame Console\u003c\/div\u003e\n\u003cdiv class=\"subBlock\"\u003eXbox360, PS4, Switch...\u003c\/div\u003e\n\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003cdiv style=\"text-align: center;\" class=\"mgnTB_p\" data-mce-style=\"text-align: center;\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\" data-mce-style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\"\u003eConnection Examples\u003c\/h2\u003e\n\u003ch4 style=\"text-align: center;\" class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 1);\"\u003eWorking With Raspberry Pi 4B\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-3.jpg\"\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003ch4 class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003eWorking With Raspberry Pi 3B+\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-5.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003ch4 class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 1);\"\u003eWorking With Raspberry Pi Zero 2 W\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-7.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003cp class=\"note\" style=\"text-align: left;\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003e\u003cem\u003eYou need to prepare additional mini HDMI adapter and USB cable\u003c\/em\u003e\u003c\/span\u003e\u003c\/p\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003ch4 class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 1);\"\u003eWorking With Jetson Nano\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-9.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003ch4 class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003eWorking With PC\u003c\/span\u003e\u003c\/h4\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-13.jpg\"\u003e\n\u003cdiv\u003e\u003cbr\u003e\u003c\/div\u003e\n\u003cdiv class=\"msg msg_warning\"\u003e\u003cspan style=\"color: rgb(194, 0, 1);\"\u003e\u003cem\u003efor reference only, the above controller boards or hosts are NOT included\u003c\/em\u003e\u003c\/span\u003e\u003c\/div\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003eIPS Display Panel\u003c\/h2\u003e\n\u003cp class=\"richDesc\" style=\"text-align: center;\"\u003e\u003cstrong\u003eExcellent Display Performance With 178° Wide Viewing Angle\u003c\/strong\u003e\u003c\/p\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-15.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003eQLED Quantum Dot Technology\u003c\/h2\u003e\n\u003ch3 style=\"text-align: center;\" class=\"richDesc\"\u003e\u003cspan style=\"color: rgb(194, 0, 0);\"\u003eWider Color Gamut\u003c\/span\u003e\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\" class=\"richDesc subBlock\"\u003e\u003cstrong\u003eColor Gamut Of This QLED Display Is Up To: SRGB 94%, NTSC 94%\u003c\/strong\u003e\u003c\/p\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/15.6HP-CAPQLED\/QLED1.jpg\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richDesc\"\u003e \u003c\/h2\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richDesc\"\u003eMore Pure Chroma\u003c\/h2\u003e\n\u003cp class=\"richDesc subBlock\"\u003e\u003cstrong\u003eChroma Of QLED Increases 58.3%, Makes The Color More Pure, More Vivid\u003c\/strong\u003e\u003c\/p\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/7HP-CAPQLED\/QLED2.jpg\"\u003e\n\u003ch2 class=\"richDesc\"\u003e \u003c\/h2\u003e\n\u003ch2 class=\"richDesc\"\u003eLonger Lifetime\u003c\/h2\u003e\n\u003cp class=\"richDesc subBlock\"\u003e\u003cstrong\u003eDue To Its Inorganic Characteristic, The Color Life Of QLED Could Be Up To 60000 Hours Without Color Degradation\u003c\/strong\u003e\u003c\/p\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/7HP-CAPQLED\/QLED3.jpg\"\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\" class=\"pdT\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\"\u003e \u003c\/h2\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\"\u003eCapacitive 10-Point Touch\u003c\/h2\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-17.jpg\"\u003e\n\u003cdiv class=\"alignl bgGrey\"\u003e\n\u003col class=\"alignl\"\u003e\n\u003cli style=\"text-align: left;\"\u003eup to 10-point touch, depending on the operating system\u003c\/li\u003e\n\u003cli style=\"text-align: left;\"\u003eup to 6H hardness toughened glass panel\u003c\/li\u003e\n\u003cli style=\"text-align: left;\"\u003eOptical Bonding, display well and dustproof\u003c\/li\u003e\n\u003c\/ol\u003e\n\u003c\/div\u003e\n\u003c\/div\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 style=\"text-align: center;\" class=\"richTitle\"\u003eSupports DDC\/CI Brightness Adjustment\u003c\/h2\u003e\n\u003cimg style=\"margin-bottom: 16px; float: none;\" src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-18.gif\"\u003e\n\u003cdiv\u003e \u003c\/div\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\n\u003ch2 class=\"richTitle\" style=\"text-align: center;\"\u003eInterface Introduction\u003c\/h2\u003e\n\u003cdiv\u003e\u003cbr\u003e\u003c\/div\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-19.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\n\u003c\/div\u003e\n\u003cdiv\u003e\n\u003ch2 style=\"text-align: center;\"\u003e \u003c\/h2\u003e\n\u003ch2 style=\"text-align: center;\"\u003eDimensions\u003c\/h2\u003e\n\u003cbr\u003e\n\u003c\/div\u003e\n\u003cdiv style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-size.jpg\" style=\"margin-bottom: 16px; float: none;\"\u003e\u003c\/div\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003ch2 class=\"richTitle\"\u003e \u003c\/h2\u003e\n\u003ch2 class=\"richTitle\"\u003eResources\u003c\/h2\u003e\n\u003cp\u003e\u003cstrong\u003eWiki: \u003c\/strong\u003e\u003ca href=\"http:\/\/www.waveshare.com\/wiki\/10.4HP-CAPQLED\" target=\"_blank\"\u003ewww.waveshare.com\/wiki\/10.4HP-CAPQLED\u003c\/a\u003e\u003c\/p\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003ch2\u003e \u003c\/h2\u003e\n\u003ch2\u003ePackage Contains:\u003c\/h2\u003e\n\u003cp\u003e\u003cstrong\u003eWeight: \u003c\/strong\u003e\u003cspan\u003e0.769 kg\u003c\/span\u003e\u003c\/p\u003e\n\u003cdiv class=\"std\"\u003e\n\u003col\u003e\n\u003cli\u003e10.4HP-CAPQLED ×1\u003c\/li\u003e\n\u003cli\u003eHDMI flat cable ~1m ×1\u003c\/li\u003e\n\u003cli\u003eUSB-A to USB-C cable ~1m ×1\u003c\/li\u003e\n\u003cli\u003eButton board ×1\u003c\/li\u003e\n\u003cli\u003eButton board cable ×1\u003c\/li\u003e\n\u003cli\u003eUSB to Type-C adapter (B) ×1\u003c\/li\u003e\n\u003cli\u003eUSB to Type-C adapter (C) ×1\u003c\/li\u003e\n\u003cli\u003eHDMI to Micro HDMI adapter ×1\u003c\/li\u003e\n\u003cli\u003eHDMI adapter ×1\u003c\/li\u003e\n\u003cli\u003eScrews pack ×1\u003c\/li\u003e\n\u003cli\u003e\n\u003cspan class=\"noteBg\"\u003eOPTIONS\u003c\/span\u003e 5V 3A Type C Power supply ×1\u003c\/li\u003e\n\u003c\/ol\u003e\n\u003cimg src=\"https:\/\/www.waveshare.com\/img\/devkit\/LCD\/10.4HP-CAPQLED\/10.4HP-CAPQLED-details-pack.jpg\"\u003e\n\u003c\/div\u003e"}
{
"product_id": 9460996342077,
"variant_id" : 48857674645821,
"variant_available" : true,
"inventory_quantity" : 3,
"inventory_management" : "shopify",
"inventory_policy" : "continue",
"image": "//thinkrobotics.com/cdn/shop/files/10.4hp-capqled-1_1.jpg?v=1717121530",
"price": "1099999",
"title": "Default Title",
"value": "Default Title"
}
10.4"
1600×720
HDMI
QLED Quantum Dot
170°
Capacitive
10-Point
USB Type-C
Toughened Glass
Optical Bonding
Supports DCC/CI
Brightness/Contrast
3.5mm Jack
4PIN Header
600cd/m²
