Industrial IoT Mini-Computer Based On CM4
Designed For Raspberry Pi Compute Module 4
Waveshare CM4 Industrial IoT Board Inside, Fast And Easy To Build A Mini-Computer
Part List Comparison
| RAW BASE BOARD | MINI-COMPUTER KIT | MINI-COMPUTER KIT + 4G MODULE | |
|---|---|---|---|
| CM4 Industrial IoT Board | √ | √ | √ |
| Metal case | √ | √ | |
| 5000rpm cooling fan | √ | √ | |
| 12V 2A power adapter | √ | √ | |
| Screwdriver and screws | √ | √ | |
| 4G module | √ | ||
| Antenna | √ | ||
| Antenna cable | √ |
Waveshare CM4 Industrial IoT Board Inside
Make It Easy To Build Your Own Raspberry Pi CM4 Mini PC
for reference only, CM4 is NOT included, 4G module and antenna are optional.
Base Board Specifications
| CM4 SOCKET | suitable for all variants of Compute Module 4 |
|---|---|
| NETWORKING | Gigabit Ethernet RJ45 connector, integrates 802.3af-compliant PoE circuit (5V/2.5A) |
| M.2 B KEY, supports 5G / 4G module | |
| SIM card slot, supports standard SIM card for 5G/4G/3G/2G communication | |
| CONNECTOR | Isolated RS485, Isolated RS232, PCIe Gen 2 x1, I2C, ADC, GPIO |
| USB | Dual USB 2.0 Type A |
| DISPLAY | Dual MIPI DSI display ports (15pin 1.0mm FPC connector) |
| CAMERA | Dual MIPI CSI-2 camera ports (15pin 1.0mm FPC connector) |
| VIDEO | Dual HDMI ports, supports 4K 30fps output |
| RTC | Real-time clock with battery socket and ability to wake Compute Module 4 |
| STORAGE | MicroSD card socket for Compute Module 4 Lite (without eMMC) variants |
| FAN HEADER | allows speed adjustment and measurement, 5V / 12V input |
| POWER INPUT | 7V~36V wide range |
| DIMENSIONS | 160 × 114mm |
Rich Peripheral Connectors
Onboard Connectors Including M.2/CSI/DSI/HDMI/USB/ETH/PCIe/RS232/RS485
Precise Cut-Out With Clear Label
Each Cut-Out Is Completely Aligned With The Connector
Cooling Fan Included
Comes With Cooling Fan, Combined With The Airflow Vent, Better Heat Dissipation
Wall Mount Support
Wall Mount Holes On Two Sides, Handy For Mounting
Application Examples
Binocular Vision, PoE Powered Raspberry Pi Projects, Or Other Industrial Context
for reference only, displays, cameras, and antennas are NOT included.
Outline Dimensions
Resources
WIKI: Compute_Module_4_PoE_4G_Board
Package Contents:
Weight: 0.672 kg
- Compute Module 4 PoE 4G Board x1
- Metal case (top and bottom) x1
- Fan-4010-PWM-12V x1
- Screwdriver x1
- Screws pack x1
- 12V 2A power adapter x1
- 4G module (Optional)
SIM7600G-H-M.2
IPEX4 to SMA cable ~15cm
Antenna 4G 8DB SMA ~17cm
What is included in the package and what parts must I provide separately?
The package includes the base board with connectors, a metal case, a 5000 rpm cooling fan, a 12V 2A power adapter, a screwdriver and screws, and optional 4G module and antenna. The Compute Module 4 itself is not included and must be supplied separately.
Is this board compatible with all Compute Module 4 variants and is the Compute Module 4 included?
Yes the CM4 socket supports all variants of Compute Module 4. The Compute Module 4 is not included in the kit.
What are the main connectivity options and expansion features?
The base board provides Gigabit Ethernet with PoE, an M2 B KEY for 5G or 4G modules, a SIM card slot, isolated RS485 and RS232, PCIe Gen 2 x1, I2C, ADC, GPIO, two USB 2.0 Type A ports, dual HDMI outputs, dual MIPI DSI and CSI ports, a microSD card slot, and an RTC with battery.
What are the power requirements and what power supply is included?
The power input accepts 7V to 36V. The kit includes a 12V 2A power adapter. The Ethernet PoE circuit provides 5V/2.5A when PoE is used.
Does the kit include cooling and mounting options?
A 5000 rpm cooling fan is included and the case provides ventilation. The metal case is included and there are wall mount holes on two sides for mounting.
