Femto Mega is a programmable multi-mode Depth and RGB camera with real-time streaming of processed images over Ethernet or USB connections. The camera uses Microsoft’s industry proven ToF technology and the NVIDIA® Jetson™ platform to deliver a software-defined Depth and RGB vision platform for computer vision and AI developers.



Performance

  • High resolution sensor provides detailed scene understanding.
  • Wide Field of View covers large area.
  • Various operating modes for different applications.


Programmability

  • In-camera processing of advanced depth vision algorithms.
  • Integrated NVIDIA Jetson Nano™ system-on-module for AI processing can remove need for dedicated compute.
  • Orbbec SDK enables easy setup and has a rich set of APIs for integration with various applications.

This device can serve as a direct replacement of Microsoft Azure Kinect



Features

  • 1 Mega Pixel ToF sensor
  • 4K RGB
  • IMU: 6DoF
  • Processor: NVIDIA Jetson Nano™
  • Data interfaces: Ethernet, USB-C 3.1
  • Power: PoE/USB-C/DC
  • Trigger/Sync Control
  • OS: Windows or Linux
  • Operating temperature: 10℃ ~ 25℃






      Technical Specs

      Product Name Femto Mega
      VID/PID 0x2BC5/0x0669
      Technology iTOF
      Shutter Type IR: Global Shutter, Color: Rolling Shutter
      Wavelength 850nm
      Data Connection Type C USB 3.0
      Gigabit Ethernet

      8 Pin-Connector*1
      Micro USB*2

      *1 for multi-device sync
      *2 for firmware upgrade and device reset
      Network Protocol RTSP, RTP
      Power Mode DC / PoE / Type C
      Power Input DC 12V 2A
      POE+/802.3at (24W)
      Type-C 5V 3A
      Operating Mode

      DC Power + Type-C Data
      Type-C Power + Type-C Data*1
      POE Power + Gigabit Ethernet Data *2

      *1 Depth & IR mode support 640 x 576 and below, Y16 format. Color mode supports 1,920 x 1,080 and below, YUY2 and MJPG format.

      *2 Color mode supports H.264 and H.265 format
      Power Consumption

      Average*:
      DC power + Type-C data: 11 W
      Type-C power + Type-C data: 10W
      POE power + Gigabit Ethernet data: 13W

      Peak*:
      DC power + Type-C data:16W
      Type-C power + Type-C data:14W
      POE power + Gigabit Ethernet data: 17W
      Operating Environment

      10℃ - 25℃,8%RH - 90 %RH
      Anti-flicker

      50Hz & 60Hz
      IMU

      6 DoF
      Frequency: 50 - 2000Hz
      Data Format: Float
      Mirror Mode

      Supported, Non-mirror is default
      Operating Environments

      Indoor, Semi-outdoor
      Dimensions

      145 mm × 115 mm × 40 mm ± 2mm
      Weight

      560g ± 3g
      Certifications

      ROHS, Reach, WEEE, CP65, EMC, FCC, IC, UKCA, Class 1 Laser
      What type of device is the camera and what data interfaces does it support?
      It is a programmable multi mode depth and RGB camera with real time streaming over Ethernet or USB. It supports data interfaces including Ethernet and USB C 3.1 and uses RTSP and RTP protocols for streaming.
      What are the operating and environmental requirements for this camera?
      The operating temperature is 10 to 25 degrees Celsius. It is designed for indoor or semi outdoor use with relative humidity from eight to ninety percent.
      Does the device include onboard AI processing or is external compute required?
      It includes an integrated NVIDIA Jetson Nano system on module for AI processing, enabling in camera processing of depth vision algorithms and potentially removing the need for a dedicated external compute. External compute can be used via Ethernet or USB if needed.
      What video and depth modes and resolutions are supported?
      Depth and IR mode supports 640 x 576 and below in Y16 format. Color mode supports 1920 x 1080 and below in YUY2 and MJPG formats. Color video also supports H.264 and H.265 formats.
      How can the device be powered and what are its physical specifications?
      Power options include DC 12V 2A, PoE plus 802.3at 24W, and Type C 5V 3A. Typical power consumption ranges from 10 to 13 W and peak values can reach 14 to 17 W. The unit measures 145 mm by 115 mm by 40 mm and weighs about 560 g.
