SIM8230G-M2 SIMCom Original RedCap Module Based On Qualcomm Snapdragon X35

SKU: WVSH0565

ā‚¹ 12,449.99

Out of stock

šŸ“¦ Min order 1
Chat with us on WhatsApp We reply quickly! Contact Us
ā± This is a pre-order item. We'll ship it as soon as it's back in stock.
SIM8230G-M2 SIMCom Original RedCap Module Based On Qualcomm Snapdragon X35ā‚¹ 12,449.99
Ask AI about this product
Open in ChatGPT Open in Claude Open in Gemini

SIM8230G-M2

SIMCom RedCap Module Based on Qualcomm Snapdragon X35

Adopts 3GPP 5G Release 17 Technology

The SIM8230G-M2 is a multi-band 5G NR / LTE-FDD / LTE-TDD module, supports 5G Standalone (SA) mode with a download speed up to 220Mbps. This module features strong expandability with abundant interfaces including USB2.0 and GPIO, etc. The module supports multiple network protocols, and provides much flexibility and ease of integration for customer's applications.

The SIM8230G-M2 adopts M.2 form factor, and AT commands are compatible with the SIM7600 / SIM8200 / SIM8260 series modules. This also minimizes the investments of customers and enables a short time-to-market.

It is designed for applications that need efficient and reliable data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, this module is ideally suited for many applications.

Ā

Features

Standard M.2 B Key interface
Low-power and lightweight 5G RedCap module
AT commands of the SIM8230G-M2 are compatible with SIM7600 / SIM8200 / SIM8260 series modules

Ā

Specifications

SIM8262E-M2 SIM8262A-M2 SIM8260G-M2 SIM8230G-M2
5G Standard 3GPP R16 3GPP R16 3GPP R16 3GPP R17
Chip Qualcomm Snapdragon X62 Qualcomm Snapdragon X35
FREQUENCY BAND
Sub-6G n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78, n79 n2, n5, n7, n12, n13, n14, n25, n30, n41, n48, n66, n71, n77, n78, n79 n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79 n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n30, n38, n40, n41, n48, n66, n70, n71, n77, n78
LTE-FDD B1, B3, B5, B7, B8, B18, B19, B20, B26, B28, B32 B2, B4, B5, B7, B12, B13, B14, B25, B26, B29, B30, B66, B71 B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B66, B71 B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B30, B66, B71
LTE-TDD B38, B39, B40, B41, B42, B43 B41, B46, B48 B34, B38, B39, B40, B41, B42, B43, B46, B48 B34, B38, B39, B40, B41, B42, B43, B48
WCDMA B1, B5, B8 B2, B4, B5 B1, B2, B4, B5, B8, B19 -
GNSS GPS, GLONASS, Beidou, Galileo, QZSS GPS, GLONASS, Beidou, Galileo, NavIC
DATA RATE
Sub-6G 2.4 Gbps / 500 Mbps 2.4 Gbps / 500 Mbps 3.47 Gbps / 460 Mbps 220 Mbps / 100 Mbps
LTE 1 Gbps / 200 Mbps 1 Gbps / 200 Mbps 1.6 Gbps / 200 Mbps 200 Mbps / 50 Mbps
HSPA+ 42 Mbps / 5.76 Mbps 42 Mbps / 5.76 Mbps 42 Mbps / 5.76 Mbps -
Applicable Regions Except Americas Americas Global
Application Examples CPE, Smart Gateway, Live Streaming, Remote Medical Treatment, Intelligent Security

Ā

SIM8262E-M2 SIM8262A-M2 SIM8260G-M2 SIM8230G-M2
SOFTWARE FUNCTIONS
Operating Systems Windows / Linux / Android
Communication Protocols TCP/IP, IPv4, IPv6, Multi-PDP, FTP, FTPS, HTTP, HTTPS, MQTTS, DNS, SSL3.0
Dial-Up RNDIS, NDIS, PPP, MBIM RNDIS, NDIS, PPP, MBIM RNDIS, NDIS, PPP, MBIM RNDIS, ECM, PPP
SMS Supports MT, MO, CB, Text, PDU
Firmware Upgrade Supports firmware upgrade via USB port
HARDWARE SPECIFICATIONS
SIM Card 1.8 V / 2.95 V
Antenna For 3G / 4G / 5G / GNSS
IPEX-4 Connectors 6 Ɨ IPEX-4 4 Ɨ IPEX-4 4 Ɨ IPEX-4 3 Ɨ IPEX-4
Power Supply 3.135 V ~ 4.4 V 3.135 V ~ 4.4 V 3.135 V ~ 4.4 V 3.4 V ~ 4.4 V
Form Factor M.2
Dimensions 42.0 Ɨ 30.0 Ɨ 2.3 mm 42.0 Ɨ 30.0 Ɨ 2.3 mm 52.0 Ɨ 30.0 Ɨ 2.3 mm 42.0 Ɨ 31.4 Ɨ 3.4 mm
Operating Temperature -30Ā ā„ƒ ~ +70Ā ā„ƒ

Ā

Compatible with Multiple Expansion Modules

Dongle Modules


USB TO M.2 B KEY

Ā USB 3.2 Gen1 5G DONGLE

Ā

HATs


5G HAT (with case)

Ā PCIe TO 4G/5G M.2 USB3.2 HAT+

5G for Jetson Nano

Ā

Resources & Services

Wiki: www.waveshare.com/wiki/SIM8230G-M2

Ā

Package Content

Weight: 0.009 kg

This is an M.2 module without antenna or base board.

SIM8230G-M2 x1

What is the SIM8230G-M2 and what is it used for?
It is a compact M.2 5G RedCap module based on Qualcomm Snapdragon X35 that provides high speed data in 5G networks.
Is the AT command set compatible with SIM7600, SIM8200 and SIM8260 series?
Yes. AT commands on the SIM8230G-M2 are compatible with SIM7600, SIM8200 and SIM8260 series modules.
What interfaces and form factor does the module expose?
The module uses a standard M.2 form factor and exposes USB2.0 and GPIO interfaces for data and control.
What network modes and data speeds does it support?
It supports 5G NR with Standalone SA mode and up to 220 Mbps download, enabling high speed connectivity.
What is included in the package and are antennas provided?
The package includes the SIM8230G-M2 module itself; antenna and base board are not included.
