AR0144 sensorā|āUSB2.0 portā|āSynchronized same-frame output
Ā
| Pixels | 2MP | |
| Sensor Chip | AR0144 | |
| Interface | USB2.0 (Type-C) | |
| Camera | Sensor Size | 1/4 inch |
| Aperture (F) | 2.2 | |
| Focal Length (EFL) | 2.88mm | |
| Field of View (FOV) | 74Ā°(D) / 65Ā°(H) / 43Ā°(V) | |
| Focusing | Fixed-focus | |
| Distortion | < 0.2% | |
| IR Filter | 650nm filter | |
| Shutter | Global shutter | |
| Image | Format Support | MJPG, YUY2 |
| Static Image Resolution | 2560 Ć 720 (1280 Ć 720) | |
| Video Recording |
MJPG: 30FPS 2560 Ć 720 60FPS 1600 Ć 600 60FPS 1280 Ć 720 60FPS 800 Ć 600 60FPS 640 Ć 480 120FPS 640 Ć 352 120FPS 640 Ć 360 YUY2: 5FPS 2560 Ć 720 10FPS 1280 Ć 720 20FPS 800 Ć 600 30FPS 640 Ć 480 30FPS 640 Ć 360 |
|
| Baseline Length | 52mm | |
| Communication | Type-C USB2.0 | |
| Operating Voltage | 5V Ā± 5% | |
| Dimensions | 66.00 Ć 30.00 Ć 17.72 (mm) | |
Ā
Ā
Synchronized driving ensures both image channels output in the same frame, enabling efficient coordination and precise synchronization
Ā
Equipped with dual distortion-free lenses with a distortion rate of less than 0.2%, delivering undistorted imaging and more accurate reproduction of real-world scenes
Ā
Onboard USB 2.0 port, driver-free, compatible with various USB hosts such as PC and smart devices, simply plug it in to start using
* for reference only, please refer to the package content for the detailed part list.
Ā
Ā
Ā
Weight: 0.015 kg
AR0144 Stereo USB Camera (A) x1
