Specifications
| Sensor |
IMX415 |
CMOS size |
1/2.8″ |
| Camera type |
Color |
Recommended
recording pixels |
Approx. 8.29MP (3840×2160) |
| Image size |
Diagonal 6.43mm |
Unit cell size |
1.45um (H) × 1.45um (V) |
| Aperture |
F2.0 |
Focal length |
3.95mm |
| FOV |
98° |
Distortion |
<1% |
| Applications |
Suitable for AI applications such as facial recognition, road marking recognition, license plate recognition, etc. |
Wide Field Of View
Onboard 98° Wide Angle Lens, Provides A Wider Picture Range And Viewing Angle
High SNR And Low Light Performance
Outline Dimensions
Resources
Wiki: https://wiki.luckfox.com/zh/luckfox-Omni3576/Debian12/Omni3576-pinout/CSI-Camera/
Package Contains:
Weight: 0.019 kg
IMX415-98 IR-CUT Camera x1
