Transmitting frequency:24GHZ,can be widely applied in business,industries,word controlling etc
Provide various frequency range standards:-UK,-F.advanced low consumption PHEMT oscillator
Independent transmitting and receiving route, can get the biggest gain,single channel operation
High sensibility,high flexibility,low cost,operating distance:15m
Not influenced by temperature,humidity,noise,air flow,dust,ray etc,adaptive to terrible environment
Strong radio frequency interference resistance,stable performance,swift response,high sensibility
Out put power is 5mW,does no harm to human bodies
Long distance detection range:15m
Small volume,easy to install
Radar wave can penetrate through non metallic object,such as board,glass,plastics,fabric textile etc,unless there are concrete wall or metal board to obstruct
Human beings or objects facing the sensor to move wil receive the best detection result
Notice:
Don't operate during the power on in case of maloperation,wrong circuit or electric shock
Avoid installing the product in exposed place to prevent damage or affecting using longevity
Install the product far away from magnetic field in case of maloperation
Install the product far waay from moving conductors in case of maloperation
