8 Bits TM1638 LED Digital Module Tube 8 Keys

SKU: ELC2031

₹ 329.99 ₹ 449.99

Out of stock

📦 Min order 1
Chat with us on WhatsApp We reply quickly! Contact Us
8 Bits TM1638 LED Digital Module Tube 8 Keys₹ 329.99
Ask AI about this product
Open in ChatGPT Open in Claude Open in Gemini
Details:
  • Weight:28 g
  • Color: as picture show
  • Size:75mmx48mm/2.95"x1.89"(inch) (approx)
  • The rated voltage: DC12V
  • Voltage range: DC7.0 V-13.6 V
  • The input power: 0.24 A
  • The rated speed: 9500 R.P.M
  • Temperature range:-10.. 70 ° C
  • Txpect life: 25 ° C L10 when expected life 50000 hours
  • Bearing structure: free maintenance dual ball bearings
  • Rotation direction: the wind from stents place eduction, facing the rotor counter-clockwise
  • The wiring way: + red-black signal: blue (blue line, the alarm line speed, it is necessary to pay attention to). Line about 20 cm long
  • The biggest air volume: 26.8 m? / h
  • The electric motor protection : overload protection, wrong level protection and stall lock current protection
  • Minimum wind pressure : 0.. 120 Pa
  • Noise index : 41.9 dB (A)
  • Material qualitative material: glass fiber reinforced plastic, PBT shell, PA blades
  • Function explain : electronic reversing the rotor dc fans, complete electronic directional control components
The TM1638 Button Digital LED Display Module is used in chip TM1638, a collection of these three common MCU peripheral circuit, the biggest feature just takes three microcontroller IO port to drive, do not need to scan display and key scanning microcontroller intervention, only need to read the relevant register send display data or test button, save MCU resources.

We usually use an external microcontroller 8 LED, 8 digital tubes, eight keys which will occupy the number of IO ports, far more than three IO mouth it, but with this module can be achieved. The practical application of key sensitive display good results. Wiring: VCC GND connected to 5V power supply, STB CLK DIO connected microcontroller IO port. The module comes with 8 buttons, 8 LED, 8 digital tube, common cathode LED digital tube, such as STC microcontroller can be directly connected


How to connect:
VCC GND 5V power supply, STB CLK DIO MCU I/O port. This module for the chip TM1638, set the above three kinds of single chip microcomputer common peripheral circuit, the biggest characteristic is to simply take microcontroller three IO mouth can drive, scanning display and key scan don't need microcontroller intervention, only need to register to display data related to reading and writing or testing buttons, save MCU resources.

Specifications

Resources

Library

Sample Code

Tutorial



What is included with this TM1638 module?
The module includes 8 buttons, 8 LEDs, and 8 digital tubes (8 digit display) with a common cathode configuration.
How do I power and wire the module to a microcontroller?
Connect VCC and GND to a 5V power supply, and connect STB, CLK, and DIO to the microcontroller IO pins.
How does the TM1638 drive interface work in terms of microcontroller IO usage?
The module is driven by the TM1638 and can be controlled using only three microcontroller IO ports, handling display data and button tests without intensive MCU intervention.
Which microcontrollers are compatible with this module?
The module is designed for common microcontrollers and can be directly connected to STC microcontrollers as an example.
Is warranty or return information available for this product?
Warranty and return details are not provided in the product description; please check the seller policy.
