RaspRover Open-source 4WD AI Robot for Raspberry Pi
Ask AI about this product
OFFERS TOP-OF-THE-LINE 10G CONNECTIVITY WITH EXCEPTIONAL 275 TOPS OF AI PERFORMANCE
DSBOARD-AGXMAX, the industrial carrier board that is built to maximize your productivity and connectivity. Powered by the high-performance AGX Orin SoM, which can deliver up to 275 TOPS of AI performance, this board offers top-of-the-line 10G connectivity, as well as Dual Gigabit Ethernet, USB 3.2, HDMI, CAN, Serial Ports, and MIPI CSI-2 Camera support.
The AGX Orin SoM processor delivers exceptional performance for industrial applications that require high-speed data transfer, real-time communication, and reliable performance. Whether youāre working on machine vision, robotics, automation, or any other industrial project, the DSBOARD-AGXMAX will deliver the power and versatility you need to get the job done.
| High-Performance AGX Orin SoM | The DSBOARD-AGXMAX is powered by the NVIDIA Jetson AGX Orin SoM, delivering up to 275 TOPS of AI performance for machine vision, robotics, industrial automation, and edge AI applications. |
| Top-of-the-Line 10G Connectivity | Features 10G Ethernet (SFP+) along with dual Gigabit Ethernet ports, enabling ultra-fast data transfer and reliable real-time communication for industrial deployments. |
| Extensive Connectivity Options | Equipped with 2 Ć USB 3.1 Type-A, 2 Ć USB-C, RS232/422/485, CAN Bus, HDMI, and MIPI CSI-2 camera support, providing seamless integration with sensors, cameras, and peripherals. |
| Advanced AI & Machine Learning | Delivers up to 275 TOPS of AI computing power, enabling real-time inference, intelligent analytics, autonomous decision-making, and advanced machine learning workloads. |
| Rugged & Durable Construction | Built for demanding industrial environments with a robust design that offers reliable operation, efficient thermal management, and resistance to dust, shock, and vibration. |
| Wide Operating Range | Supports operation in temperatures ranging from -25Ā°C to +85Ā°C and accepts a wide 12Vā32V DC input, ensuring dependable performance in diverse industrial applications. |
Ā
Ā
JETSON AGX ORIN CARRIER BOARD WITH 10G ETHERNET - DSBOARD-AGXMAX USE CASES
| Application | Description |
|---|---|
| Autonomous Systems | Enables seamless deployment in autonomous systems including self-driving vehicles, drones, mobile robots, and intelligent robotic platforms. Supports real-time perception, navigation, obstacle avoidance, and decision-making in dynamic environments. |
| Energy | Facilitates predictive maintenance of energy infrastructure, analyzes sensor data for improved operational efficiency, and integrates with smart grid technologies to enhance energy management, monitoring, and grid stability. |
| Robotics | Powers advanced robotics applications with real-time perception, AI inference, motion planning, and control capabilities, enabling robots to perform complex tasks in manufacturing, logistics, warehousing, inspection, and service industries. |
Ā
TECHNICAL SPECIFICATIONS
| Parameter | Specification |
|---|---|
| Supported Modules | NVIDIA Jetson AGX Orin 32GB NVIDIA Jetson AGX Orin 64GB NVIDIA Jetson AGX Orin Industrial |
| Memory | 32GB 256-bit LPDDR5x 64GB 256-bit LPDDR5 |
| Graphics Interface | 1 Ć HDMI 2.0 (Max Resolution: 3840 Ć 2160) |
| Networking | 2 Ć Gigabit Ethernet 1 Ć 10G Ethernet (SFP+ Based) |
| USB Interfaces | 2 Ć USB 3.1 Type-A 2 Ć USB-C (Debug / Recovery) |
| Industrial Interfaces | 1 Ć CAN Bus 1 Ć RS232/422/485 (Software Configurable) |
| Digital I/O | 2 Ć Digital Inputs 3 Ć Digital Outputs |
| Wireless Expansion | Wi-Fi / Bluetooth / LTE / 5G via Extension Sockets |
| Power Supply | 12V ā 30V DC |
| Extension Sockets | 1 Ć M.2 Key-B 1 Ć M.2 Key-E 1 Ć SIM Slot 1 Ć 11V/5V Fan Header 1 Ć IĀ²C 2 Ć UART 1 Ć IĀ²S 2 Ć SPI 1 Ć CAN 1 Ć Camera Connector (Supports up to 6 CSI Cameras) |
| Mass Storage | 64GB eMMC 5.1 Flash 2 Ć M.2 Key-M SSD Slots |
| Operating Temperature | -25Ā°C to +85Ā°C |
| Dimensions | 140 mm Ć 125 mm |
| Weight | 132 g |
| Operating System | Ubuntu Linux 20.04 / 22.04 |
| JetPack Support | JetPack 5.x / 6.x |
Ā
Documents & Models
| Datasheet | View |
| 3D Model | View |
| JetPack 5.x Installation | View |
| JetPack 6.x Installation | View |
| Getting Started Guide | View |
| Connector Definitions | View |
| User Manual | View |
What are the main network and peripheral interfaces on this board?
The board provides 1x 10G Ethernet (SFP+ based), 2x Gigabit Ethernet, 2x USB 3.1 Type A, 2x USB C for debug and recovery, CAN bus, RS232/422/485, HDMI 2.0 and MIPI CSI-2 camera support with a camera connector for up to six cameras.
What memory configurations are available for the Jetson AGX Orin module on this board?
Supported memory options include 32 GB LPDDR5x and 64 GB LPDDR5 for the NVIDIA Jetson AGX Orin module.
What are the operating temperature and input power requirements?
It operates from -25 C to 85 C and supports an input power range of 12 to 32 V DC.
Is this board suitable for industrial applications such as machine vision and autonomous systems?
Yes. It offers up to 275 TOPS of AI performance, a rugged fanless design, and extensive I/O to support machine vision, robotics and autonomous platforms.
What storage options and expansion capabilities does it provide?
The board includes 64 GB eMMC 5.1 flash and two M.2 Key-M SSD slots, plus extension options such as M.2 Key-B, SIM, and multiple I/O interfaces for expansion.
