DSBOARD-AGX is a powerful and reliable edge computing device designed for industrial applications that require high processing power and ruggedness. It is based on the NVIDIA Jetson AGX Orin system- on-module (SOM), which features an NVIDIA Ampere GPU with 1024 CUDA cores and up to 275 TOPS (trillion operations per second) of AI performance. The AGX Orin SOM also includes a 12-core ARMv8.2 CPU and a dedicated deep learning accelerator for efficient inferencing.
| High-Performance AGX Orin SoM | Powered by the NVIDIA Jetson AGX Orin SoM, delivering up to 275 TOPS of AI performance for advanced robotics, industrial automation, machine vision, and edge AI applications. |
| Advanced AI & Video Capabilities | Supports high-resolution video output up to 8K@60fps via HDMI 2.0b, making it ideal for intelligent video analytics, industrial visualization, and AI-driven imaging systems. |
| Extensive Connectivity Options | Equipped with Gigabit Ethernet, USB 3.1, HDMI 2.0b, CAN Bus, and RS232/422/485 interfaces for seamless integration with industrial equipment, sensors, and control systems. |
| Versatile Expansion Slots | Features M.2 Key-B, M.2 Key-M, and PCIe x4 expansion slots, allowing flexible customization with storage devices, communication modules, and application-specific peripherals. |
| Robust & Reliable Design | Industrial-grade construction with efficient thermal management, providing reliable operation in demanding environments while offering protection against dust, vibration, and shock. |
| Wide Operating Range | Supports operation from -25Ā°C to +85Ā°C and accepts a wide 12Vā32V DC input range, ensuring stable performance across diverse industrial deployments. |
Ā
| Security & Surveillance | FORECR's industrial-grade computing solutions powered by NVIDIA Jetson modules enable advanced security and surveillance systems, providing real-time analysis of video streams and sensor data for enhanced threat detection, monitoring, and rapid response capabilities. |
| Healthcare | Supports high-performance medical imaging, diagnostics, and AI-assisted healthcare applications, enabling faster and more accurate analysis to improve patient care and clinical outcomes. |
| Robotics | Delivers powerful edge computing capabilities for robotics, enabling real-time perception, navigation, decision-making, and control for applications in manufacturing, logistics, autonomous systems, and service robotics. |
Ā
| Parameter | Specification |
|---|---|
| Supported Modules | NVIDIA Jetson AGX Orin 32GB NVIDIA Jetson AGX Orin 64GB |
| Memory | 32GB 256-bit LPDDR5x 64GB 256-bit LPDDR5x |
| Graphics Interface | 1 Ć HDMI 2.0 (Max Resolution: 3840 Ć 2160) |
| Interfaces | 1 Ć Gigabit Ethernet 2 Ć USB 3.1 Type-A 1 Ć CAN Bus 1 Ć RS232/422/485 (Software Configurable) 2 Ć USB-C (Debug / Recovery) 2 Ć Digital Inputs 3 Ć Digital Outputs |
| Wireless Communication | LTE / 5G Connectivity via Extension Sockets |
| Power Supply | 12V ā 30V DC |
| Extension Sockets | 1 Ć M.2 Key-B 1 Ć SIM Slot 1 Ć MicroSD Slot 1 Ć 11V/5V Fan Header 1 Ć SPI 1 Ć UART 1 Ć IĀ²C 1 Ć PCIe (x4) 1 Ć IĀ²S 1 Ć XFI for 10G 1 Ć Camera Connector (Supports up to 6 CSI Cameras) |
| Mass Storage | 64GB eMMC 5.1 Flash 1 Ć M.2 Key-M SSD Slot |
| Operating Temperature | -25Ā°C to +85Ā°C |
| Dimensions | 100 mm Ć 100 mm |
| Weight | 103 g |
| Operating System | Ubuntu Linux 20.04 / 22.04 |
| JetPack Support | JetPack 5.x / 6.x |
Ā
| Datasheet | View |
| 3D Model | View |
| JetPack 5.x Installation | View |
| JetPack 6.x Installation | View |
| Getting Started Guide | View |
| Connector Definitions | View |
| User Manual | View |
Ā
Note: AGX ORIN SoM Not Included
