Electret Condenser Microphone

SKU: ELC1074

ā‚¹ 29.99

Out of stock

šŸ“¦ Min order 1
Chat with us on WhatsApp We reply quickly! Contact Us
Electret Condenser Microphoneā‚¹ 29.99
Ask AI about this product
Open in ChatGPT Open in Claude Open in Gemini


  • Temperature:Ā -25 ~ + 70Ā Ā° C
  • Rel, Humidity:Ā 35% ~ 85% RH
  • Pressure:Ā 86 ~ 106Kpa
  • Environmental noise:Ā Maximum: 36dB
  • Operating voltage:Ā 1 ~ 10VDC
  • Operating Voltage Standard:Ā 2VDC
  • Impedance:Ā Maximum: 2.2k Ī©
  • Current consumption:Ā Maximum: 0.5mA
  • Sensitivity:Ā Ā (0dB = 1 V / Pa, 1 KHz)Ā -58dB Ā± 3dB Vs = 2 V R1 = 2.2k Ī©
  • Directivity:Ā Omni-directional
  • S / N ratio:Ā Minimum: 58dB
  • Test temperature:Ā 20Ā Ā° CĀ Ā± 2Ā Ā° C
  • Rel. Humidity:Ā 45% ~ 65% RH
Specifications

Resources
Datasheet

Sample Code

Tutorial
What operating voltage does this microphone support?
The operating voltage range is 1 to 10 VDC. The standard operating voltage is 2 VDC.
What is the sensitivity and impedance specification?
Sensitivity is -58 dB +/- 3 dB at 1 kHz, with 0 dB defined as 1 V per Pa. Impedance is maximum 2.2 kOhm.
Is the microphone directional?
Directivity is Omni-directional.
What are the environmental and operating condition ranges?
Temperature range is -25 to 70 C, humidity range 35 to 85 percent RH, and pressure range 86 to 106 kPa, with environmental noise maximum 36 dB. Test temperature is 20 C +/- 2 C.
What about noise performance and current consumption?
SNR minimum is 58 dB. Current consumption maximum is 0.5 mA.
