Ā USER-ORIENTED 6-AXIS COBOT Ā Open ROS simulation development environment, built-in kinematics forward and inverse solution algorithm. The whole series has been sold to 60+ countries around the world with more than 5,000 units shipped. Start your intelligent manufacturing robot learning journey anytime, anywhere! |
|
Ā Empower Your Projects with myCobot Ā M5 version robotic arms are jointly produced by Elephant Robotics and Shenzhen Mingzhan Technology Co., Ltd. - M5STACK. It adopts Esp32 as its core processor and applies two screens and several physical buttons to be used on a table-sized ground. Deeply integrated with M5 expensive ecosystem, users are able to control robots via UIFlow, Python, and Arduino in accordance with the tutorial provided on our official website. |
 |
 |
Ā DIY your personal mechanical assistant Ā Equipped with up to 12 standard 24V industrial I/O interfaces, it can be expanded to develop PLC control independent programming, support mainstream control interfaces, and a wealth of terminal expansion accessories to help explore the boundaries of personal applications. |
|
Ā Creative Visual Development Ā myCobot 320 M5 is a free-to-match visual development application, intuitive structural analysis of mechanical motion principles, and enterprise-level communication protocol specifications and applications. |
 |
 |
Ā OPEN-SOURCE INTERFACES Ā Based on different kinds of applications, open source to its interfaces and enables to achieve objects recognition, facial recognition, image recognition etc. |
|
Ā SECONDARY DEVELOPMENTS Ā Easily learn to program myCobot in your style and ready to start your robotics journey. Ā |
 |
 |
Ā PARAMETERS Ā myCobot 320 robotic arm boasts a 350mm working radius, with1000g payload, and 1mm repeatability, as an ideal solution for your scene exploration needs. |
|
Ā Ā Multiple adapters meet the requirements of a variety of application scenarios Ā |
 |
Ā
Ā
24V industrialized electrical interface, to complete your industrial scene development needs, key interaction, screen display, PLC interface, allowing you to quickly and safely build robotic arm application exploration scenarios.
Ā
Ā
Developing in ROS - the world's mainstream robot communication framework, you can control myPalletizer and conduct algorithm verification in under a virtual environment, which reduces the requirements for the experimental environment and improves the experimental efficiency.
Ā
| Degree of Freedom | 6 |
| Payload | 1000g |
| Weight | 3360g |
| Working Radius | 350mm |
| Positioning Accuracy | Ā±0.5mm |
| Working Temperature | -5ā ~ 45ā |
| Working Lifespan | 2000h |
| Power Input | DC 24V 120W |
| Joint Rotation Range | |
|---|---|
| Joint1 | -165Ā° ~ +165Ā° |
| Joint2 | -165Ā° ~ +165Ā° |
| Joint3 | -165Ā° ~ +165Ā° |
| Joint4 | -165Ā° ~ +165Ā° |
| Joint5 | -165Ā° ~ +165Ā° |
| Joint6 | -175Ā° ~ +175Ā° |
| Joint Maximum Speed | 160Ā°/s |
| Controller | |
| Master | ESP32 |
| Main Frequency | 240MHz dual core |
| Computing Performance | 600DMIPS |
| SRAM | 520KB |
| Flash | 4M |
| Bluetooth | Dual mode Bluetooth 2.4G/5G |
| WiFi | 802.11ac |
| Development | |
| Development Platforms (OS) | Windows, Linux, MacOS |
| Programming | Python, C++, C#, JavaScript |
| ROS | ROS1 |
| Communication Protocol | Serial Communication, MODBUS, TCP/IP |
| Development Software | myBlockly, myStudio, UiFlow, Arduino |
| Interfaces | |
| Type-C | 1 |
| I/O Interfaces | INPUT Ć6, OUTPUT Ć6 |
Ā
