CM5 IO Board

An Application Board for Radxa CM5

Radxa CM5 with Radxa CM5 IO Board

Quick Functional Verification of 3x100Pin

Interface Details

Camera 2x MIPI CSI	Display 2x MIPI DSI, 1x HDMI	Storage 1x Micro SD Card Slot	USB 2x USB 2.0 HOST Type A Port, 1x USB 3.0 HOST Type A Port, 1x USB 3.0 OTG Type C Port
WiFi / BT 1x M.2 E Key Connector	Ethernet 1x Gigabit Ethernet with PoE Support	Audio Headphone Jack with Microphone Input	40-Pin GPIO I2S, UART, SPI, PDM, I2C, PWM, GPIO, 5V Power Out, 3.3V Power Out

Interfaces

Tech Specs

Category	Specifications
Display	2x MIPI DSI 1x HDMI USB3.0 OTG Type C Port
Camera	2x MIPI CSI
USB	1x USB3.0 HOST Type-A Port 1x USB3.0 OTG Type-A Port 2x USB2.0 HOST Type-A Ports
Ethernet	1x Gigabit Ethernet with PoE support
Storage	1x MicroSD Card Slot
Connectivity	1x Fan Header 1x M.2 E Key Connector for Wi-Fi / BT 40-Pin GPIO Header 1x Headphone Jack with Microphone Input
Dimensions	160mm x 90mm

Download

Product Information

Schematic V2.2	Download
Components Placement Map	Download
2D Drawings	Download

What interfaces does the IO board expose?

The board exposes 2x MIPI CSI, 2x MIPI DSI, 1x HDMI, USB 2.0 host ports, 1x USB 3.0 host port, 1x USB 3.0 OTG Type C port, an M.2 E Key connector for WiFi and BT, Gigabit Ethernet with PoE, a 40 pin GPIO header, a headphone jack with microphone input, and a micro SD card slot.

Is this board compatible with Radxa CM5 modules?

Yes, it is an application board designed for the Radxa CM5 to provide quick functional verification of the interfaces.

What storage options are supported?

There is a Micro SD Card Slot for storage.

What are the power and connectivity features?

It provides 5V and 3.3V power out, Gigabit Ethernet with PoE support, and a fan header for cooling.

What are the physical dimensions and key connectors?

The board measures 160 mm by 90 mm and includes a 40 pin GPIO header plus an M2 E Key connector for wifi and BT.
