Best seller

Radxa

Radxa ROCK 5 ITX+

SKU: RDXA1231

₹ 15,999.99

Out of stock

Select variant

RAM 4GB

4GB 8GB 16GB 24GB 32GB

Chat with us on WhatsApp We reply quickly! Contact Us

Radxa ROCK 5 ITX+4GB₹ 15,999.99

Ask AI about this product

Open in ChatGPT Open in Claude Open in Gemini

ROCK 5 ITX+

New Upgrade Version of ROCK 5 ITX

Welcome to the ARM PC Era

It's time to build your ARM PC

8-Core 8K AI Mini-ITX Motherboard

RK3588 SoC

4x SATA Interfaces or M.2 M Key Connector,
Storage Solution Is Up to You

Powerful Multimedia Capabilities

Quiet Operation

Supports up to 4 Displays Concurrently

Dual HDMI, eDP with Touch Panel, MIPI DSI, DP via Type-C

A Groundbreaking Breakthrough in SATA Storage

Paired with the Radxa M.2 to Hexa SATA Adapter,
enabling storage expansion with 12 SATA interfaces.

Standard Motherboard Specifications

Compatible with Standard Computer Case

Power Output and Multiple Power Input Options
Integrated in One

ROOBI OS

Effortlessly Resolving ARM System Installation Challenges

ROOBI OS is Pre-installed on Onboard eMMC

Personal NAS Server

Network Server

Light Home Office

Multimedia Entertainment System

Edge Computing

Interfaces

Tech Specs

Radxa ROCK 5 ITX+ Specifications
SoC	Rockchip RK3588
CPU	Quad Cortex-A76 @ 2.2~2.4GHz + Quad Cortex-A55 @ 1.8GHz
GPU	Arm Mali-G610MC4 - OpenGL ES1.1 / 2.0 / 3.2 - OpenCL 1.1 / 1.2 / 2.2 - Vulkan 1.1 / 1.2 - 2D image acceleration module
NPU	Supports INT4 / INT8 / INT16 / FP16 / BF16 / TF32 Up to 6 TOPs computing power
RAM	LPDDR5: 4GB / 8GB / 16GB / 32GB
Multimedia	Decoder: H.265 / VP9 / AVS2 up to 8K@60fps H.264 up to 8K@30fps Encoder: H.265 / H.264 up to 8K@30fps
Storage	1x eMMC (ROOBI OS) 1x microSD Card Slot 2x M.2 M Key (PCIe 3.0 x2) 1x SPI Flash (Bootloader)
Audio	1x Headphone Jack 1x Microphone Jack 1x Front Audio Header 1x S/PDIF
Video Output	2x HDMI (8K@60 + 4K@60) 1x DP via USB-C (4K@60) 2x 4-lane MIPI DSI 1x eDP with Touch Support Supports 4 simultaneous displays
Video Input	1x HDMI Input (up to 4K@60) 2x 4-lane or 4x 2-lane MIPI CSI
USB	4x USB 3.0 Type-A 2x USB 2.0 Type-A 1x USB 3.0 OTG/Host Type-C 2x USB 2.0 via Front Header
Ethernet	2x 2.5G Ethernet (PoE support with module)
Wireless	1x M.2 E Key Slot for Wi-Fi 6
Other Interfaces	1x PWM Fan Connector 1x RTC Socket (CR1220 battery) 1x Front Panel Header (Power / Reset / LED)
Power	1x 12V DC Jack (5.5x2.5mm) 1x 24-Pin ATX Power Header 1x PoE Header (via add-on module)
Operating System	Radxa OS / Debian / Android
Operating Conditions	Recommended: 0 ~ 50°C Throttles above 80°C for reliability Use heatsinks or fans for continuous high-performance workloads
Dimensions	170mm x 170mm
Compliance	FCC / CE

What operating systems are available on the Radxa ROCK 5 ITX and is ROOBI OS included?

ROOBI OS is pre installed on onboard eMMC and the board also supports Radxa OS, Debian, and Android.

How many displays can be driven at the same time and which video interfaces are supported?

Up to four displays concurrently via 2x HDMI, DP via USB C, eDP with touch, and MIPI DSI.

How can I expand storage and what interfaces are available?

The board has 1x eMMC for ROOBI OS, 1x microSD, 2x M.2 M Key PCIe 3.0 x2, and 1x SPI Flash bootloader. With the Radxa M.2 to Hexa SATA Adapter you can expand to up to 12 SATA interfaces.

What are the power inputs and cooling recommendations for reliable performance?

Power is provided via a 12V DC jack, a 24 pin ATX power header, or a PoE header via an add on module. For continuous high performance use heatsinks or fans and keep within 0 to 50 C operating range. Throttling occurs above 80 C.

Is the board compatible with standard computer cases and what are its dimensions?

Yes it is compatible with standard computer cases. Dimensions are 170 mm by 170 mm.

A

Admin

Welcome to the discussion thread for Radxa ROCK 5 ITX+
Feel free to ask questions, share tips or report issues.
