Features
- 10 Separately Controlled LED's
- High Brightness
- High-Intensity Green Output
- Ideal for Audio and Meter Displays
- Economically priced
- Easy to Mount
- RoHS Compliant
-
Display
- LED Size: 2 x 5 mm
- Material: GaAlAs
-
Absolute Maximum Ratings
- Power Dissipation (Pd): 65 * 10 mw
- Forward Current (If): 25 mA
- Peak Forward Current (Ifp): 250 mA
-
Electro-Optical Data (@ 10 mA)
- Forward Voltage - Typical: 1.85 V
- Forward Voltage - Maximum: 2.2 V
- Luminous Intensity Typical: 120 Mcd
Specifications
