10 Segment LED Bar Graph

SKU: ELC2007R

₹ 19.99 ₹ 59.99

In stock | Ready to ship

Select variant

Red
⚠ Only a few left in stock. Order soon.
⏱ High demand right now.
📦 Min order 1
Chat with us on WhatsApp We reply quickly! Contact Us
10 Segment LED Bar GraphRed₹ 19.99
Ask AI about this product
Open in ChatGPT Open in Claude Open in Gemini

Features

  • 10 Separately Controlled LED's
  • High Brightness
  • High-Intensity Green Output
  • Ideal for Audio and Meter Displays
  • Economically priced
  • Easy to Mount
  • RoHS Compliant
  • Display
    • LED Size: 2 x 5 mm
    • Material: GaAlAs
  • Absolute Maximum Ratings
    • Power Dissipation (Pd): 65 * 10 mw
    • Forward Current (If): 25 mA
    • Peak Forward Current (Ifp): 250 mA
  • Electro-Optical Data (@ 10 mA)
    • Forward Voltage - Typical: 1.85 V
    • Forward Voltage - Maximum: 2.2 V
    • Luminous Intensity Typical: 120 Mcd
Specifications

Resources

Datasheet

Sample Code

Tutorial
How many segments does the bar graph have and can each segment be controlled separately?
It has 10 separately controlled LEDs with high brightness green output, suitable for audio and meter displays.
What are the electrical ratings for operation?
Forward current If is 25 mA, peak forward current Ifp is 250 mA, forward voltage typical 1.85 V and maximum 2.2 V, using GaAlAs material.
Is it RoHS compliant and easy to mount?
Yes RoHS compliant and easy to mount; LED size is 2 x 5 mm.
What are ideal uses for this display?
Ideal for audio and meter displays; supports 10 segments for level indication.
What documentation is available to aid integration?
Technical resources include the datasheet, sample code, and tutorials.
