Part Number: D2VW2055M
Manufacturer: OMRON ELECTRONIC COMPONENTS
Country of Origin: CN
Unit of Measure: EA
ECCN: EAR99
Package Type: Not specified
Datasheet: Download Datasheet
Product Features
Sealed miniature basic switch conforming to IP67 standards (excluding terminals on terminal models)
Uses epoxy resin for stable sealing, ideal for environments with water spray or excessive dust
High precision and durability guaranteed by V-series internal mechanism
Suitable for automotive, agricultural machinery, large home appliances, and industrial equipment requiring high environmental resistance
RoHS compliant for environmentally conscious applications
Technical Specifications
Ratings
Actuator
Contact Form
Current Rating
5 A
Pin Plunger, Short Hinge Lever, Hinge Lever, Long Hinge Lever, Short Hinge Roller Lever, Hinge Roller Lever, Simulated Roller Lever
SPDT, SPST-NC, SPST-NO
0.1 A (for D2VW-01 models)
Model Variants and Contact Configurations
Model
Terminals
Contact Form
Model Number
Solder Terminals
HS, UL Approved
SPDT, SPST-NC, SPST-NO
D2VW-5-1, D2VW-5-2, D2VW-5-3
Molded Lead Wires (300 mm)
MS, UL Approved
SPDT, SPST-NC, SPST-NO
D2VW-5-1M, D2VW-5-2M, D2VW-5-3M
Molded Lead Wires (1,000 mm)
MS, UL Approved
SPDT, SPST-NC, SPST-NO
D2VW-5-1M-0, D2VW-5-2M-0, D2VW-5-3M-0
Additional Models with Safety Certification
Model
Contact Form
Rated Voltage
Current Rating
D2VW-5L1A-1HS, D2VW-01L1A-1HS
SPDT, SPST-NC, SPST-NO
125 VAC / 250 VAC
3 A
D2VW-5L1A-1MS, D2VW-01L1A-1MS
SPDT, SPST-NC, SPST-NO
125 VAC / 250 VAC
3 A
Mechanical and Electrical Characteristics
Permissible operating speed: 0.1 mm to 1 m/s (pin plunger models)
Durability: Mechanical ≥10 million operations, Electrical ≥100,000 operations
Degree of protection: IEC IP67 (excluding terminals on terminal models)
Operating temperature: –40°C to 85°C
Operating humidity: Up to 95% RH (no icing or condensation)
Mounting and Dimensions
Includes mounting holes of 2-3.1 mm diameter. Dimensions vary by actuator type; see datasheet for detailed measurements.
