Introducing the OMRON D2VW2245E, a high-quality sealed snap action switch designed for demanding applications requiring watertight and high-precision performance. Manufactured in China, this miniature limit switch complies with RoHS standards and is suitable for various industrial and electronic uses.
Watertight, high-precision miniature snap action switch with IP67 compliance
Use of epoxy resin ensures high sealing capability, ideal for dusty or water-sprayed environments
V-series internal mechanism provides high precision and long operational life
Available in general load (5 A at 250 VAC) and micro-load models
RoHS compliant for environmentally conscious applications
Specifications
Characteristics
Model D2VW-01
Model D2VW-5
Operating speed
0.1 mm to 1 m/s (at pin plunger)
Operating frequency
Mechanical: 300 ops/min, Electrical: 60 ops/min
Insulation resistance
≥100 MΩ (at 500 VDC)
Contact resistance
≤50 mΩ (solder terminal models), ≤100 mΩ (300 mm lead wires), ≤200 mΩ (1,000 mm lead wires)
Dielectric strength
1,000 VAC (same polarity), 1,500 VAC (ground and terminal separation)
Vibration resistance
Malfunction at 10-55 Hz, 1.5 mm amplitude
Shock resistance
Destruction: 1000 m/s², Malfunction: 300 m/s²
Degree of protection
IEC IP67 (excluding terminals)
Ambient operating temperature
-40°C to 85°C
Life expectancy
Mechanical: ≥10 million operations, Electrical: ≥1 million operations
Weight
Approx. 7 g (pin plunger models without wires)
Ordering Information
Actuator
Terminal
Model
Pin plunger
With solder and #187 tab terminals
D2VW-01-1HS (0.1 A), D2VW-5-1HS (5 A)
With lead wires
D2VW-01-1MS, D2VW-5-1MS
Short hinge lever
With solder and #187 tab terminals
D2VW-01L1A-1HS, D2VW-5L1A-1HS
With lead wires
D2VW-01L1A-1MS, D2VW-5L1A-1MS
Hinge lever
With solder and #187 tab terminals
D2VW-01L1-1HS, D2VW-5L1-1HS
With lead wires
D2VW-01L1-1MS, D2VW-5L1-1MS
Long hinge lever
With solder and #187 tab terminals
D2VW-01L1B-1HS, D2VW-5L1B-1HS
With lead wires
D2VW-01L1B-1MS, D2VW-5L1B-1MS
Simulated roller lever
With solder and #187 tab terminals
D2VW-01L3-1HS, D2VW-5L3-1HS
With lead wires
D2VW-01L3-1MS, D2VW-5L3-1MS
Short hinge roller lever
With solder and #187 tab terminals
D2VW-01L2A-1HS, D2VW-5L2A-1HS
With lead wires
D2VW-01L2A-1MS, D2VW-5L2A-1MS
Hinge roller lever
With solder and #187 tab terminals
D2VW-01L2-1HS, D2VW-5L2-1HS
With lead wires
D2VW-01L2-1MS, D2VW-5L2-1MS
For detailed specifications, please refer to the datasheet.
Note: Datasheet was not processed, please search the internet for the part number for more details.
Note: The product image displayed is a standard reference image. Actual product appearance may vary. For the most accurate and up-to-date representation, we recommend searching the part number online.
