Product Description: Circular Connector MIL-DTL-38999 Plug 56 Position
Introducing the TE CONNECTIVITY / DEUTSCHPart Number: DTS26S25-04SA, a high-performance circular connector designed for demanding aerospace and military applications. Manufactured in France (COO: FR), this connector complies with MIL-DTL-38999 standards and offers superior sealing, durability, and EMI protection.
Key Features
Threaded coupling with self-locking mechanism for secure connection
Designed for aerospace and military applications requiring high reliability and environmental resistance
Elastomer silicone seals provide maximum tear resistance and sealing memory
Elongated mounting holes facilitate interchangeability with existing MIL-DTL-38999 receptacles
Grounding fingers ensure effective EMI protection
Compatible with standard mounting styles and arrangements
Additional Details
For more detailed technical information, please refer to the datasheet. This connector is suitable for applications requiring robust environmental sealing, EMI shielding, and secure locking mechanisms. Ensure compatibility with your system specifications before ordering.
Note: The datasheet was not processed; please search the internet for the part number for more details.
Note: The product image displayed is a standard reference image. Actual product appearance may vary. For the most accurate and up-to-date representation, we recommend searching the part number online.
