FYSETC Cheetah V3.0 STM32F446 MCU motherboard for Voron

Onboard CANBUS Circuit | Supports 5V 4A Max

Features：

  • Compact size: 101.5mm x 72mm
  • Compatible with the Creatlity ender 3/ender5 motherboard size
  • Fully integrated all in one solution: STM32F446 MCU (Run Marlin 2.0/Klipper)
  • 4X TMC2209 stepper drivers, Support sensor-less homing
  • UNIVERSAL POWER: 24V to 12V/2A DC-DC for fans
  • Integrated high precision power regulators (DC/DC): 5V 4A Max and 3.3V 800mA Max LDO
  • 12V & 24V power pin out
  • Onboard TF card socket
  • EXP3 for 12864 display panel (Creality 12864 panel or FYSETC Generic12864)
  • EXP1&EXP2 RepRapDiscount SmartController compatible pin header on board
  • Onboard 5V WS2812 RGB control
  • Onboard CANBUS Circuit
  • 5-Pin Bltouch Interface（Share IO with Probe and Z-Min）
  • SD card & USB upload support
  • Car fuses（15A） for main power input
  • Indicates all the name of PINS on the bottom
  • Up to 3 ways PWM fans (5/12/24 Optional)
  • Reliable PCB: Four Layers, TG155 FR4, Plug Hole, Immersion Gold



What are the main features of the FYSETC Cheetah V3.0 board?
It is an all in one 101.5 mm by 72 mm board with an STM32F446 MCU, 4x TMC2209 stepper drivers, sensorless homing, and a built in CANBUS circuit. It also provides 24V to 12V DC DC for fans, 5V 4A max and 3.3V 800 mA max regulators, and supports Marlin 2.0 and Klipper.
Is this board compatible with Ender 3 and Ender 5 size printers?
Yes, it is compatible with the Creality Ender 3 and Ender 5 motherboard size.
How many stepper drivers are on the board and does it support sensorless homing?
The board includes four TMC2209 stepper drivers and supports sensorless homing.
What power options and voltage regulation does the board provide?
It supports 24V main power input, with a 24V to 12V/2A DC DC converter for fans, and onboard 5V 4A max and 3.3V 800 mA max regulators.
What display options and IO headers are available for interfacing with panels and controllers?
The unit has an onboard TF card socket EXP3 for 12864 display panels, EXP1 and EXP2 for RepRapDiscount SmartController, 5V WS2812 RGB control, and it supports SD card and USB upload.
