The HBW-M-R is a high-quality fuse holder manufactured by Eaton Electronics, designed for reliable circuit protection in electronic applications. This product is compliant with RoHS standards and features a robust construction suitable for various mounting configurations.
Part Number: HBW-M-R
Manufacturer: Eaton Electronics
Country of Origin: MX
Unit of Measure: EA (Each)
ECCN: EAR99
Package Type: BLK (Black)
For detailed technical specifications and installation guidelines, please refer to the datasheet.
Product Features
Designed for 5 mm x 20 mm fuse carriers
Vertical mounting configuration without stability pins
Spring-loaded bayonet type fuse carrier and knob with screwdriver slot for easy replacement
Interchangeable fuse carriers for versatile use
High dielectric molded thermoplastic material meeting UL 94V0 standards
Resistance ratings:
Insulation resistance: 10,000 megaohm at 500 Vdc
Contact resistance: Less than 0.005 ohms at 200 mV
Dielectric strength exceeding 200 V/mil for reliable insulation
Operating temperature range from -40°C to +85°C
Mounting body rated for 150°C; knob rated for +130°C
Specifications
Specification
Details
Fuse Carrier Size
5 x 20 mm
Voltage Rating
250 V
Current Rating
16 A
Agency Approvals
UL Recognized, CSA Certified, VDE, SEMKO
Body Mount
Horizontal
Packaging
10 fuse holders per carton; 100 per shelf package (BK suffix)
RoHS Compliance
-R suffix indicates RoHS compliance
Note: Eaton reserves the right to modify product design and specifications without prior notice. This product is not authorized for use in life support systems without express written approval from Eaton.
Datasheet was not processed please search the internet for the part number for more details.
Note: The product image displayed is a standard reference image. Actual product appearance may vary. For the most accurate and up-to-date representation, we recommend searching the part number online.
