High Resolution 1500TVL FPV Camera 2.1mm Lens 1/3" SUPER HAD II CCD with integrated OSD For RC FPV Racing Drone

SKU: DRO8006

₹ 1,599.99 ~~₹ 1,995.00~~

Out of stock

Chat with us on WhatsApp We reply quickly! Contact Us

High Resolution 1500TVL FPV Camera 2.1mm Lens 1/3" SUPER HAD II CCD with integrated OSD For RC FPV Racing Drone₹ 1,599.99

Ask AI about this product

Open in ChatGPT Open in Claude Open in Gemini

This 1500TVL CMOS Camera can be used as both PAL and NTSC. The toggle switch is provided on the camera for switching between PAL and NTSC.

This camera is very compact and easy to use. This camera is tailored for FPV which offers delicate clear image, micro ultralight design, high definition color.

Specifications:

Image Sensor: 1/3" Mg SUPER HAD II CCD
Horizontal Resolution: 1500TVL
Lens: 2.1mm
S/N Ratio: >600dB (AGC Off)
Electronic Shutter Speed: 1/50 ~ 100,000 (PAL), 1/60 ~ 100,000 (NTSC)
Autogain Control (AGC): Low/Middle/High
Backlight Compensation: Yes
Min. Illumination: 0.001 Lux / 1.2F
WDR: D-WDR
DNR: 3DNR
Day/Night: Color/Auto/B&W
Power: 5- 30V
Net Weight: 15 grams
Dimensions: 22.0mm X 25.0mm X 28.00mm

OSD Adjustments:

Exposure Brightness / exposure mode / gain
White Balance: Automatic tracking white balance
Day & Night Mode: Internal Automatic / Color Mode / B&W Mode
Video Settings: Contrast / Sharpness / Saturation / Digital Noise / Video Format (NTSC/PAL)
Language: Chinese/ English / Russian / Italian / German

What video formats does this FPV camera support and how do I switch between PAL and NTSC?

The camera supports both PAL and NTSC formats and includes a toggle switch to select between them. Set the switch to PAL for PAL output or NTSC for NTSC output.

What power supply is required to operate the camera?

The device operates from 5 to 30 volts. Make sure your power source provides a supply within this range.

What are the key image and sensor features of this camera?

It uses a 1/3 inch SUPER HAD II CCD with 1500TVL resolution and a 2.1mm lens. It offers high definition color and features like WDR and 3DNR for better image quality.

What are the weight and dimensions of the camera body?

Net weight is 15 grams. Dimensions are 22.0 mm x 25.0 mm x 28.0 mm.

What OSD and video settings are available and what languages are supported?

The built in OSD provides exposure brightness, exposure mode and gain, automatic white balance, and day night mode. It also offers video format selection (NTSC or PAL) and controls for contrast, sharpness, saturation, and digital noise, with language options including Chinese English Russian Italian and German.
