Industrial 4G DTU, RS485 TO LTE CAT4, DIN Rail-Mount
RS485 TO LTE CAT4
Industrial Rail-Mount 4G DTU
Features
The RS485 TO LTE CAT4 (EU) is a DIN Rail mounted RS485 cellular modem with European bands, which can realize the data transmission between RS485 and 4G Network. Reliable Serial to 4G Cellular Communication. With RS485 interfaces, full network coverage, wide temperature and wide voltage, multi center transmission. Provides wireless data communications between field serial devices and the central control system to enable remote control of industrial field sites. It is ideal for M2M and IoT applications including distribution automation, smart metering, water & wastewater, heating, street light monitoring and etc.
Specifications
Models RS485 TO LTE CAT4 (EU)
Applicable regions EMEA, Korea, Thailand, India, Southeast Asia
LTE Category LTE Cat.4
Frequency Bands LTE FDD
B1/B3/B7/B8/B20/B28A
LTE TDD
B38/B40/B41
WCDMA
B1/B8
GSM
B3/B8
Transmission Speed LTE-FDD
150Mbps(DL)/50Mbps(UL)
LTE-TDD
130Mbps(DL)/30Mbps(UL)
DC-HSDPA
42Mbps (DL)
HSUPA
5.76Mbps (UL)
WCDMA
384Kbps(DL)/384Kbps(UL)
GSM(EDGE)
296Kbps (DL)/236.8Kbps (UL)
GSM (GPRS)
107Kbps (DL)/85.6Kbps (UL)
Serial Parameters Interface form
RS485(Terminal)*1
Data Bits
8
Stop Bits
1,2
Parity Bits
NONE,ODD,EVEN
Baud Rate
2400~230400
Physical Interfaces SIM/USIM card
1.8V/3V
Antenna
SMA Female
USB
USB 2.0
Indicators
POWER,WORK,NET,LINK,RSSI
Reload
Button
Hardware Characteristics Input Voltage
9V~36V
Connector
Terminal
Housing material
ABS Plastic
Dimensions(mm)
L × W × H: 109.66 × 28 × 64.71 mm
Operating temperature
-30℃~+75℃
Storage Temperature
-40℃~+85℃
Operating humidity
5%~95%
Storage humidity
5%~95%
Primary function
RS485 Port, realizing data transmission between RS485 and 4G Network
Rail-mount serial server
DIN rail-mount support, tiny size, easy installation, cost effective
Function block diagram
Multi working modes
Feature functions
Multi Configuration Ways
Socket Distribution
Hardware Protection
User-defined Hartbeat/Registration Packet
Outline dimensions
Resources
Wiki: www.waveshare.com/wiki/RS485_TO_LTE_CAT4_(EU)
Package Contents
Weight: 0.228 kg (power supply not included)
