NEMA23 HYBRID STEPPER MOTOR with Optional Gearbox

SKU: MOT5113

₹ 2,899.99 ₹ 3,299.99

In stock | Ready to ship

Select variant

1.8° 57HS112-3004A08-D21
No Gearbox
⚠ Only a few left in stock. Order soon.
⏱ High demand right now.
📦 Min order 1
Chat with us on WhatsApp We reply quickly! Contact Us
NEMA23 HYBRID STEPPER MOTOR with Optional Gearbox1.8° 57HS112-3004A08-D21 / No Gearbox₹ 2,899.99
Ask AI about this product
Open in ChatGPT Open in Claude Open in Gemini

DEWO Motors 0.9°/1.8° NEMA23 2-Phase Hybrid Stepper Motor



Specifications:

  1. Model: 57HM56-3004A08-D21
  2. Step Angle: 0.9° ± 5%
  3. Rated Voltage: 2.7VDC
  4. Rate Current: 3.0A
  5. Phase Resistance: 0.9±10%Ω
  6. Phase Inductance: 3.5±20%mH
  7. Holding Torque: 10 Kg.cm
  8. Surface Treatment: Black Electrophoresis
  9. Dielectric Strength: 500VAC / 5mA / 1min
  10. Insulation Resistance: ≥100M Ω / 500VDC
  11. Insulation: Class B
  12. Wires: AWG26 UL1007
  13. Motor Length: 56mm
  14. Motor Weight: 700grams
  15. Shaft Profile: D
  16. Shaft Diameter: 8mm
  17. Shaft Length: 21mm
  18. Shaft Radial Play 0.02Max.(450g-load)
  19. Shaft Axial Play 0.08Max.(450g-load)


Specifications:

  1. Model: 57HS56-3004A08-D21
  2. Step Angle: 1.8° ± 5%
  3. Rated Voltage: 2.85VDC
  4. Rate Current: 3.0A
  5. Phase Resistance: 2.95±10%Ω
  6. Phase Inductance: 2.8±20%mH
  7. Holding Torque: 12 Kg.cm
  8. Surface Treatment: Black Electrophoresis
  9. Dielectric Strength: 500VAC / 5mA / 1min
  10. Insulation Resistance: ≥100M Ω / 500VDC
  11. Insulation: Class B
  12. Wires: AWG26 UL1007
  13. Motor Length: 56mm
  14. Motor Weight: 700grams
  15. Shaft Profile: D
  16. Shaft Diameter: 8mm
  17. Shaft Length: 21mm
  18. Shaft Radial Play 0.02Max.(450g-load)
  19. Shaft Axial Play 0.08Max.(450g-load)

Specifications:

  1. Model: 57HS51-1504A08-D21
  2. Step Angle: 1.8° ± 5%
  3. Rated Voltage: 2.4VDC
  4. Rate Current: 1.5A
  5. Phase Resistance: 1.6±10%Ω
  6. Phase Inductance: 3.8±20%mH
  7. Holding Torque: 8.2 Kg.cm
  8. Surface Treatment: Black Electrophoresis
  9. Dielectric Strength: 500VAC / 5mA / 1min
  10. Insulation Resistance: ≥100M Ω / 500VDC
  11. Insulation: Class B
  12. Wires: AWG26 UL1007
  13. Motor Length: 51mm
  14. Motor Weight: 650grams
  15. Shaft Profile: D
  16. Shaft Diameter: 8mm
  17. Shaft Length: 21mm
  18. Shaft Radial Play 0.02Max.(450g-load)
  19. Shaft Axial Play 0.08Max.(450g-load)

Specifications:

  1. Model: 57HS82-3004A08-D21
  2. Step Angle: 1.8° ± 5%
  3. Rated Voltage: 4.2VDC
  4. Rate Current: 3.0A
  5. Phase Resistance: 1.4±10%Ω
  6. Phase Inductance: 5.0±20%mH
  7. Holding Torque: 22.0 Kg.cm
  8. Surface Treatment: Black Electrophoresis
  9. Dielectric Strength: 500VAC / 5mA / 1min
  10. Insulation Resistance: ≥100M Ω / 500VDC
  11. Insulation: Class B
  12. Wires: AWG26 UL1007
  13. Motor Length: 82mm
  14. Motor Weight: 1200grams
  15. Shaft Profile: Round
  16. Shaft Diameter: 8mm
  17. Shaft Length: 21mm
  18. Shaft Radial Play 0.02Max.(450g-load)
  19. Shaft Axial Play 0.08Max.(450g-load)

      Specifications:

      1. Model: 57HS112-3004A08-D21
      2. Step Angle: 1.8° ± 5%
      3. Rated Voltage: 3.9VDC
      4. Rate Current: 3.0A
      5. Phase Resistance: 1.3±10%Ω
      6. Phase Inductance: 6.5±20%mH
      7. Holding Torque: 30.0 Kg.cm
      8. Surface Treatment: Black Electrophoresis
      9. Dielectric Strength: 500VAC / 5mA / 1min
      10. Insulation Resistance: ≥100M Ω / 500VDC
      11. Insulation: Class B
      12. Wires: AWG26 UL1007
      13. Motor Length: 60mm
      14. Motor Weight: 1.7Kg
      15. Shaft Profile: D
      16. Shaft Diameter: 8mm
      17. Shaft Length: 21mm
      18. Shaft Radial Play 0.02Max.(450g-load)
      19. Shaft Axial Play 0.08Max.(450g-load)


      NOTE: If you just need the NEMA23 Reducing Gearbox, please contact us.

      Drawings

       57HM56-3004A08-D21​


      57HS56-3004A08-D21

      57HS51-1504A08-D21

      57HS82-3004A08-A21

      57HS112-3004A08-D21

      GEARBOX DRAWING

      What motor variants are available in this NEMA23 line and what are their step angles?
      The lineup includes a 0.9 degree variant 57HM56-3004A08-D21 and several 1.8 degree variants such as 57HS56-3004A08-D21, 57HS51-1504A08-D21, 57HS82-3004A08-D21, and 57HS112-3004A08-D21.
      What are the electrical specifications for the 0.9 degree model and the 1.8 degree models?
      The 0.9 degree model uses rated voltage 2.7VDC, rate current 3.0A, phase resistance 0.9 ohm and phase inductance 3.5 mH. The 1.8 degree models use rated voltage 2.85VDC, rate current 3.0A, phase resistance 2.95 ohm and phase inductance 2.8 mH.
      What is the holding torque and basic dimensions across the models?
      Holding torque ranges from 8.2 to 30 Kg.cm depending on the variant. For example the 0.9 degree variant 57HM56-3004A08-D21 has 10 Kg.cm, while the 57HS112-3004A08-D21 has 30 Kg.cm. Motor lengths vary from 51 to 82 mm and weights from 650 g to 1.7 kg.
      Is a gearbox available as an option and how do I order it?
      Yes, the NEMA23 reducing gearbox is available as an option. Please contact us to arrange the gearbox.
      Where can I find warranty, delivery or returns information for this product?
      The product information does not specify warranty, delivery times, or returns. Please contact ThinkRobotics for details.
