RUT901 - Industrial Cellular Router

Name: RUT901 - Industrial Cellular Router
Brand: Teltonika Networks
SKU: ELC8719
Price: 13599.99 INR
Availability: InStock

SKU: ELC8719

₹ 13,599.99

₹ 13,599.99 ~~₹ 27,199.99~~

Sale Sold out

/

Tax included. Shipping calculated at checkout.

Looking for Bulk?

This is a pre order item. We will ship it when it comes in stock.

Quantity must be 1 or more

Description

The RUT901 cellular router delivers the top-rated features of its predecessors, the RUT950 and RUT951, to the market. The device ensures high-performance, providing automatic WAN failover to an available backup connection, guaranteeing network continuity and eliminating downtime.

Standard package*

*Standard package contents may differ based on standard order codes.

Features

Mobile

Feature	Details
Mobile Module	4G LTE Cat 4 (up to 150 DL/50 UL Mbps), 3G (up to 21 DL/5.76 UL Mbps), 2G (up to 236.8 DL/236.8 UL kbps)
3GPP Release	Release 9
SIM Switch	2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection
Status	IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band, signal strength (RSSI, SINR, RSRP, RSRQ), EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC
SMS	SMS status, SMS configuration, send/read SMS via HTTP POST/GET, email-to-SMS, SMS-to-email, SMS-to-HTTP, SMS-to-SMS, scheduled SMS, SMS auto-reply, SMPP
USSD	Sending and reading Unstructured Supplementary Service Data (USSD) messages
Black/White List	Operator black/white list by country or separate operators
Multiple PDN	Use different PDNs for multiple network access and services
Band Management	Band lock, used band status display
SIM Idle Protection Service	SIM cards remain idle when not in use
SIM PIN Code Management	Set, change, or disable SIM PIN
APN	Auto APN
Bridge	Direct connection (bridge) between mobile ISP and device on LAN
Passthrough	Assign router’s mobile WAN IP to another device on LAN

Wireless

Feature	Details
Wireless Mode	802.11b/g/n (Wi-Fi 4), Access Point (AP), Station (STA)
Wi-Fi Security	WPA2-Enterprise, WPA3, OWE, AES-CCMP, TKIP, client separation, EAP-TLS with PKCS#12 certificates
SSID/ESSID	SSID stealth mode, access control via MAC address
Wi-Fi Users	Up to 100 simultaneous connections
Wireless Connectivity Features	Fast roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource measurement (802.11k)
Wireless MAC Filter	Allowlist, blocklist
Wireless QR Code Generator	Enables network access via QR code
TravelMate	Forward Wi-Fi hotspot landing page to subsequent devices

Ethernet

Feature	Details
WAN	1 x WAN port 10/100 Mbps, compliance with IEEE 802.3 standards
LAN	3 x LAN ports, 10/100 Mbps, compliance with IEEE 802.3 standards

Network

Feature	Details
Routing	Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy-based routing
Network Protocols	TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On LAN (WOL), VXLAN
VoIP Passthrough Support	H.323 and SIP-ALG protocol NAT helpers for proper VoIP packet routing
Connection Monitoring	Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP link inspection
Firewall	Port forward, traffic rules, custom rules, TTL target customization
Firewall Status Page	View firewall statistics, rules, and rule counters
Ports Management	View and manage device ports: enable/disable, auto-configuration, transmission speed settings
Network Topology	Visual representation of connected devices and their network relationships
Hotspot	Captive portal, Radius server, SMS authentication, customizable landing pages, user scripts, themes
DHCP	Static/dynamic IP allocation, DHCP relay, server configuration, static leases (MAC with wildcards)
QoS / Smart Queue Management (SQM)	Traffic priority by source/destination, service, protocol, or port, WMM, 802.11e
DDNS	Supported for >25 service providers; manual configuration available
DNS over HTTPS	Secure DNS resolution via HTTPS proxy
Network Backup	Wi-Fi WAN, Mobile, VRRP, Wired options for automatic failover
Load Balancing	Balance internet traffic across multiple WAN connections
SSHFS	Remote file system mounting via SSH protocol (not available in standard firmware)
Traffic Management	Real-time monitoring, wireless signal charts, traffic usage history
Port Mirroring	Mirror Ethernet traffic for monitoring and analysis

Security

Feature	Details
Authentication	Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator
Firewall	Preconfigured firewall rules via WebUI, unlimited configuration via CLI, DMZ, NAT, NAT-T, NAT64
Attack Prevention	DDOS prevention (SYN flood, SSH, HTTP/HTTPS attack prevention), Port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
VLAN	Port and tag-based VLAN separation
Mobile Quota Control	Mobile data limit, customizable period, start time, warning limit, phone number
Web Filter	Blacklist for unwanted websites, Whitelist for allowed websites
Access Control	Flexible access for SSH, Web interface, CLI, and Telnet
SSL Certificate Generation	Let's Encrypt and SCEP certificate generation methods

VPN

VPN Protocol	Details
OpenVPN	Multiple clients and server support, 27 encryption methods
OpenVPN Encryption	DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES (128/192/256) GCM, CFB, CFB1, CFB8, OFB
IPsec	XFRM, IKEv1, IKEv2, with 14 encryption methods (3DES, DES, AES128/192/256, AES128GCM8/12/16, AES192GCM8/12/16, AES256GCM8/12/16)
GRE	GRE tunnel and GRE over IPsec support
PPTP/L2TP	Client/Server support, L2TPv3, L2TP over IPsec
Stunnel	Proxy adding TLS encryption without code changes
DMVPN	Scalable IPsec VPNs, Phase 2 and 3, Dual Hub support
SSTP	SSTP client instance support
ZeroTier	ZeroTier VPN client support
WireGuard	WireGuard VPN client and server support
Tinc	Tinc with encryption, authentication, and compression; Client and server support

MODBUS

Feature	Details
Supported Modes	Server, Client
Supported Connection Types	TCP
Custom Registers	MODBUS TCP custom register block requests for reading/writing to a file inside the router, extending Client functionality
Supported Data Formats	8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII

Data to Server

Feature	Details
Protocol	HTTP(S), MQTT, Azure MQTT, Kinesis
Data to Server	Extract parameters from multiple sources/protocols and send to a single server; Custom LUA scripting for advanced functionality

MQTT Gateway

Feature	Details
Modbus MQTT Gateway	Send commands and receive data from MODBUS Server through MQTT broker

DNP3

Feature	Details
Supported Modes	Station, Outstation
Supported Connection	TCP

DLMS

Feature	Details
DLMS Support	Standard protocol for utility meter data exchange
Supported Modes	Client
Supported Connection Types	TCP
COSEM	Automatic detection and configuration of meter COSEM objects

API

Feature	Details
Teltonika Networks Web API	Beta support for configurable API endpoints to retrieve or change data. Documentation available at: https://developers.teltonika-networks.com

Monitoring & Management

Feature	Details
WEB UI	HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status
FOTA	Firmware update from server, automatic notification
SSH	SSH (v1, v2)
SMS	SMS status, SMS configuration, send/read SMS via HTTP POST/GET
Call	Reboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer, Wi-Fi on/off
TR-069	OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
MQTT	MQTT Broker, MQTT publisher
SNMP	SNMP (v1, v2, v3), SNMP Trap, Brute force protection
JSON-RPC	Management API over HTTP/HTTPS
RMS	Teltonika Remote Management System (RMS)

IoT Platforms

Platform	Features
ThingWorx	Monitor WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network Type
Cumulocity - Cloud of Things	Monitor Device Model, Revision, Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength. Includes reboot and firmware upgrade actions
Azure IoT Hub	Configurable with Data to Server to send available parameters to the cloud. Supports Direct method for RutOS API calls. Plug and Play integration with Device Provisioning Service
AWS IoT Core	Utility to interact with AWS cloud platform. Supports AWS Jobs functionality for device API calls

System Characteristics

Feature	Details
CPU	Mediatek, 580 MHz, MIPS 24KEc
RAM	128 MB, DDR2
FLASH Storage	16 MB, SPI Flash

Firmware / Configuration

Feature	Details
WEB UI	Update firmware from file, check firmware on server, configuration profiles, configuration backup
FOTA	Update firmware
RMS	Update firmware/configuration for multiple devices simultaneously
Keep Settings	Update firmware without losing current configuration
Factory Settings Reset	Full factory reset restores all system settings to default, including IP address, PIN, and user data

Firmware Customisation

Feature	Details
Operating System	RutOS (OpenWrt-based Linux OS)
Supported Languages	Busybox shell, Lua, C, C++
Development Tools	SDK package with build environment provided
GPL Customisation	Create custom, branded firmware and web page application by changing colors, logos, and other elements
Package Manager	Install additional software on the device via Package Manager

Input / Output

Category	Details
Input	1 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high
Output	1 x Digital Output, Open collector output, max output 30 V, 300 mA
Events	Email, RMS, SMS
I/O Juggler	Allows setting specific I/O conditions to initiate events

Power

Feature	Details
Connector	4-pin industrial DC power socket
Input Voltage Range	9 – 30 VDC, reverse polarity protection; surge protection >31 VDC 10us max
PoE (Passive)	Passive PoE over spare pairs; power via LAN1 port; Mode B, 9 - 30 VDC (not compatible with IEEE standards)
Power Consumption	< 2 W idle, < 7 W Max

Physical Interfaces

Category	Details
Ethernet	4 x RJ45 ports, 10/100 Mbps
I/O's	1 x Digital Input, 1 x Digital Output on 4-pin power connector
Status LEDs	1 x Bi-color connection status, 5 x Mobile connection strength, 4 x ETH status, 1 x Power
SIM	2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, external SIM holders, eSIM (optional, different hardware required)
Power	1 x 4-pin power connector
Antennas	2 x SMA for LTE, 2 x RP-SMA for Wi-Fi antenna connectors
Reset	Reboot/User default reset/Factory reset button

Physical Specification

Feature	Details
Casing Material	Aluminium housing, plastic panels
Dimensions (W x H x D)	110 x 50 x 100 mm
Weight	297 g
Mounting Options	DIN rail, wall mount, flat surface (all require additional kit)

Operating Environment

Feature	Details
Operating Temperature	-40 °C to 75 °C
Operating Humidity	10% to 90% non-condensing
Ingress Protection	IP30

Regulatory & Type Approvals

Category	Details
Regulatory	CE, UKCA, IMDA, Anatel, RCM, E-mark, ECE R118, CB, RoHS, REACH, NCC

EMC Emissions & Immunity

Category	Standards
General	EN 55032:2015 + A11:2020 + A1:2020, EN 55035:2017 + A11:2020
Harmonics & Flicker	EN IEC 61000-3-2:2019 + A1:2021, EN 61000-3-3:2013 + A1:2019 + A2:2021
Wireless	EN 301 489-1 V2.2.3, EN 301 489-17 V3.2.4, EN 301 489-52 V1.2.1
Immunity	EN 61000-4-2:2009 (ESD), EN IEC 61000-4-3:2020 (Radiated Immunity), EN 61000-4-4:2012 (EFT), EN 61000-4-5:2014 + A1:2017 (Surge Immunity), EN 61000-4-6:2014 (CS), EN 61000-4-11:2020 (DIP)

RF

Standards	Details
Wireless Standards	EN 300 328 V2.2.2, EN 301 511 V12.5.1, EN 301 908-1 V15.1.1, EN 301 908-2 V13.1.1, EN 301 908-13 V13.1.1

Performance Specifications

Category	Standards
CE	EN IEC 62368-1:2020 + A11:2020, EN IEC 62311:2020, EN 50665:2017
CB	IEC 62368-1:2018
RCM	AS/NZS 62368.1:2022
