SIM8200EA-M2 Industrial 5G Router

INDUSTRIAL 5G WIRELESS ROUTER

High Speed 5G, Multi Mode Multi Band

Incorporates SIM8200EA-M2 5G Module, Supports 5G/4G/3G, And 5G SA / NSA
Applicable For Regions With 5G Sub-6G Signal Coverage Except The Americas

Specifications

Multi Mode Multi Band

Applicable For Most Of The Countries And Regions

High Speed 5G Network Experience

RS232/RS485 Serial Communication

Supports Multi Modes Including TCP/UDP Transparent Forwarding, Modbus, And MQTT

Industrial Design, Stable & Reliable

More Safe & Stable Data Transmission

Customizable Software/Hardware

Interface

Dimensions

Package Contents:

Customer Reviews

Custom Requirements?

Download the ThinkRobotics Mobile App

We are here to serve you! Reach us at:

Popular Links

Shopping Cart

Let customers speak for us

5G WIRELESS SPECIFICATION
FREQUENCY BAND	5G Sub-6G (SA): n1, n2, n3, n5, n7, n8, n12, n20, n28, n38, n40, n41, n48, n66, n71, n77, n78 5G Sub-6G (NSA): n41, n77, n78
	LTE-FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B66, B71
	LTE-TDD: B34, B38, B39, B40, B41, B42, B43, B48
	WCDMA: B1, B2, B3, B4, B5, B8
	GNSS: GPS, GLONASS, BeiDou, Galileo, and QZSS
DATA RATE	5G Sub-6G: 2.4 Gbps (DL) / 500 Mbps (UL)
	LTE: 1 Gbps (DL) / 200 Mbps (UL)
	HSPA+: 42 Mbps (DL) / 5.76 Mbps (UL)
WIFI WIRELESS SPECIFICATION
WIFI STANDARD	IEEE802.11b/g/n, IEEE802.11Wi-Fi 5(a/b/g/n/ac) compliant, 2.4GHz, 5.8GHz, 2T2R, supports AP mode
DATA RATE	2.4GHz: up to 300Mbps 5.8GHz: up to 866Mbps
AUTHENTICATION	supports encryption methods including WEP, WPA, WPA2, etc.
INTERFACES
M.2	1x connector, comes with 1x SIM8200EA-M2 module by default, supports other 5G modules
MINI PCIE	3x connectors, comes with 1x 2.4GHz and 1x 5.8GHz WiFi module, allows connecting one more 4G module
WAN	1x 10 / 100 / 1000M Ethernet, auto-negotiation MDI/MDIX, embedded 1.5KV electromagnetic isolation protection (the WAN RJ45 can be used as LAN RJ45 port, so there could be totally 5x LAN RJ45 port)
LAN	4x 10 / 100 / 1000M Ethernet, auto-negotiation MDI/MDIX, embedded 1.5KV electromagnetic isolation protection
SERIAL PORT	1x RS232 + 1x RS485, embedded ESD protection
SIM/UIM CARD SLOT	drawer SIM card slot, prevents the SIM card from dropping out, embedded 15KV ESD protection
ANTENNA CONNECTOR	SMA standard antenna connector, comes with 6x 5G antennas, 4x WiFi antennas by default
TF CARD SLOT	for external storage
POWER SUPPLY	standard power supply interface, supply 12~24V input, embedded power supply phase-reversal protection and over-voltage protection
RESET BUTTON	press and hold for 5~10s then release, restores the router to factory setting
INDICATORS	PWR, SYS, 5G, 4G, WAN, LAN, TF, 2.4G, 5.8G status indicators
POWER SUPPLY
POWER ADAPTER	DC 12V/2A
POWER INPUT RANGE	12 ~ 24V
POWER CONSUMPTION	data mode: ＜1A@12V, idle mode: ＜500mA@l2V
MECHANICAL
CASE	Metal case, IP30 protection level
DIMENSIONS	195 × 107 × 37mm
OPERATING TEMPERATURE	-35 ~ +75ºC
STORAGE TEMPERATURE	-40 ~ +85ºC
RELATIVE HUMIDITY	95% (non-condensing)
