OMRON ELECTRONIC COMPONENTS DIP SWITCH - Part Number: A6T-0104
Enhance your electronic assemblies with the reliable and high-quality OMRON A6T-0104 DIP Switch. Designed for standard through-hole mounting, this slide DIP switch features gold-plated twin contacts to ensure high reliability and durability in various applications.
Product Features
Standard through-hole mounting slide DIP switch for easy integration
Gold-plated twin contacts for enhanced electrical reliability
Available with flat or raised actuators, with or without seal tape
Models supporting from 1 to 10 poles to meet diverse needs
RoHS compliant for environmentally conscious design
Washable models available with seal tape; others are not washable
Technical Specifications
Rating (resistive load)
25 mA at 24 VDC, 10 A minimum current at 3.5 VDC
Ambient Operating Temperature
–20°C to +70°C (no icing or condensation)
Ambient Operating Humidity
35% to 95% at +5°C to +35°C
Insulation Resistance
≥100 MΩ at 250 VDC
Contact Resistance (initial)
≤200 mΩ
Dielectric Strength
Between terminals: 500 VAC for 1 minute
Vibration Resistance
Malfunction at 10 to 55 Hz, 1.5-mm double amplitude
Shock Resistance
≥300 m/s²
Electrical Durability
≥1,000 operations
Degree of Protection
IEC IP40
Operating Force
0.29 to 9.8 N (30 to 1,000 gf)
Weight
0.26 g (2 poles), 0.44 g (4 poles), 0.62 g (6 poles), 0.79 g (8 poles), 0.96 g (10 poles)
Dimensions (mm)
Flat Actuator (Standard/With Seal Tape)
Model
Dimension A (mm)
A6T-1101 / A6T-1102 / A6T-1104
3.48
A6T-2101 / A6T-2102 / A6T-2104
6.02
A6T-3101 / A6T-3102 / A6T-3104
8.56
A6T-4101 / A6T-4102 / A6T-4104
11.10
A6T-5101 / A6T-5102 / A6T-5104
13.64
A6T-6101 / A6T-6102 / A6T-6104
16.18
A6T-7101 / A6T-7102 / A6T-7104
18.72
A6T-8101 / A6T-8102 / A6T-8104
21.26
A6T-9101 / A6T-9102 / A6T-9104
23.80
A6T-0101 / A6T-0102 / A6T-0104
26.34
Raised Actuator
Model
Dimension A (mm)
A6T-1104
7.62
Internal Connections
Contact form and connection details are specified in the datasheet. For comprehensive information, refer to the datasheet.
Additional Information
Package Type: Not specified
ECCN: EAR99
UOM: EA
Country of Origin: CN
Note: The datasheet was not processed; please search the internet for the part number A6T-0104 for more details.
For safety and proper application, please read all safety precautions and verify the product specifications before use.
