Industrial IoT 5G/4G Wireless Expansion Module Designed for Raspberry Pi Compute Module 4, With UPS Module

Industrial IoT module Based on CM4 With UPS Module

suitable for IoT applications like IoT getaway, wireless router, intelligent data acquisition...

4G/5G Support, Multi Interfaces, Onboard UPS Module

Specifications

Connecting with Compute Module 4

standard CM4 socket and partial Raspberry Pi GPIO header
suitable for Compute Module 4 Lite/eMMC series module

4G/5G Wireless modules support

Onboard M.2 B KEY Slot, Compatible With 4G/5G Wireless Modules With M.2 B Connector

Features:

Rich interfaces

Rail-mount support

rail-mount ABS protection case, easy to install, safer operation

Application example

What's On Board

Outline dimensions

Resources

Package Contains:

Want to buy in bulk?

Customer Reviews

Custom Requirements?

Download the ThinkRobotics Mobile App

We are here to serve you! Reach us at:

Popular Links

Shopping Cart

Let customers speak for us

CM4 socket	suitable for all variants of Compute Module 4
UPS Power	UPS Module, 5V/2.5A (Max) output, supports 3 × 10440 lithium batteries (NOT included)
Networking	Gigabit Ethernet RJ45
	M.2 B KEY, for connecting 5G / 4G wireless module
	Nano-SIM card slot, supports standard Nano-SIM card for 5G/4G/3G/2G communication
USB	USB 2.0 × 3
Pin header	Non-isolated RS485 × 2, Non-isolated CAN × 1, Partial GPIO pins
Camera	MIPI CSI-2 × 1 (15pin 1.0mm FPC connector)
Video	HDMI × 1, supports 4K 30fps output
RTC	Real-time clock with battery socket and ability to wake Compute Module 4
Storage	TF card socket for Compute Module 4 Lite (without eMMC) variants
Fan header	5V/12V, allows speed adjustment and measurement
Power input	5V or 7~36V
Dimensions	145 × 90 × 40mm
