RDK S100 MCU Port Expansion Board

Gigabit Ethernet Port | CAN Port | 30PIN header | IMU

The RDK S100 MCU Port Expansion Board is specifically designed for the RDK S100 development kit. It adapts the core interfaces of the main control MCU Domain, allowing users to easily connect various peripherals and accelerating the testing and development process.

Specifications

100PIN Connector	For connecting the RDK S100 development board
CAN Interface	Onboard 5 × CAN screw terminals
Ethernet Port	Onboard 1 × Gigabit Ethernet port
30PIN Header	Adapting 7 × ADC, 2 × I2C, and 2 × SPI interfaces
IMU	Onboard BMI088 3-axis sensor for attitude and motion data acquisition
Operating Temperature	0℃ ~ 45℃ (suitable for most industrial environments)
Outline Dimensions	70 × 70 × 17 (mm)

What's On Board

1. MCU expansion board 100PIN connector
for connecting to the RDK S100 development board

2. CAN screw terminal × 5

3. RJ45 Gigabit Ethernet port

4. 30PIN header

Outline Dimensions

Resources

Wiki: www.waveshare.com/wiki/RDK-S100-MCU-Port-Expansion-Board

Package Content

Weight: 0.06 kg

RDK S100 MCU Port Expansion Board x1
Screws pack x1
RDK S100 MCU Port Expansion Board FPC x1

What interfaces are available on the expansion board and how do they help testing peripherals?

It provides five CAN screw terminals, a Gigabit Ethernet RJ45 port, a 100PIN connector to the RDK S100, and a 30PIN header for ADC, I2C, and SPI interfaces. It also includes BMI088 3-axis IMU for attitude and motion data.

Is this module compatible with other development kits besides the RDK S100?

It is designed specifically for the RDK S100 development kit and connects via the 100PIN connector to the MCU domain. Compatibility with other kits is not specified.

What should I know about warranty and returns?

Warranty and returns information is not provided in this listing; please consult the seller policy for details.

What are the physical size and operating conditions?

The board measures 70 by 70 by 17 millimeters and is rated to operate from 0 to 45 degrees Celsius.

What is included in the package when I order?

The package contains the RDK S100 MCU Port Expansion Board, a screws pack, and an FPC cable.
