Name: Serial to Ethernet - USR-TCP232-410s
Brand: PUSR
SKU: ELC8530
Price: 3479.99 INR
Availability: InStock

{"id":9805966180669,"title":"Serial to Ethernet - USR-TCP232-410s","handle":"serial-to-ethernet-usr-tcp232-410s","description":"\u003ch1 style=\"text-align: center;\"\u003eUSR-TCP232-410s\u003c\/h1\u003e\n\u003ch3 style=\"text-align: center;\"\u003eRS232 and RS485 to Ethernet Converter\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eUSR-TCP232-410s is 2 serial Port Secure Serial Device Server which can connect RS-232\/485 serial devices to the TCP\/IP network. It supports bi-directional communication, edge computing, Modbus gateway, MQTT gateway and etc.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eUSR-TCP232-410s |Dual Ports Serial Device Server\u003c\/h3\u003e\n\u003ch4 style=\"text-align: center;\"\u003eRS485+RS232, MQTT+SSL, Modbus Gateway, Edge Computing\u003c\/h4\u003e\n\u003cp style=\"text-align: center;\"\u003eUSR-TCP232-410s is 2 serial Port Secure Serial Device Server which can connect 1*RS232 and 1*RS485 serial devices to the TCP\/IP network. It supports bi-directional communication, Modbus RTU\/TCP protocol conversion, edge computing and other advanced features. This product features for its Cortex-M7 core and the main frequency is up to 400MHz, which can ensure the high processing speed and stable data transmission.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-1.jpg?v=1737701220\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eKey Features\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003e1. \u003cstrong\u003eDual Serial Ports: \u003c\/strong\u003eRS485+RS232, can work simultaneously.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e2.\u003cstrong\u003e MQTT: \u003c\/strong\u003eCan connect to IoT platform with standard MQTT.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e3. \u003cstrong\u003eSSL Encryption: \u003c\/strong\u003eTo ensure data communication security.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e4.\u003cstrong\u003e Edge computing: \u003c\/strong\u003eUp to 300 points, reporting data in JSON format.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e5. \u003cstrong\u003eModbus Gateway: \u003c\/strong\u003eModbus TCP\/RTU protocol conversion.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e6.\u003cstrong\u003e Industrial Design: \u003c\/strong\u003e-40℃~+85℃, 5-36V DC power.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e7. \u003cstrong\u003eRich Protocol: \u003c\/strong\u003eTCP\/UDP\/MQTT\/HTTP.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e8. \u003cstrong\u003eUser-defined Webpage: \u003c\/strong\u003eUser can customize the webpage.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-2.jpg?v=1737701220\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eSerial to Ethernet,\u003cbr\u003eBidirectional Transparent Data Transmission\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eWith serial device server, traditional serial devices can be connected to local networks and the Internet, then users can transform traditional serial device into IOT device to achieve remote monitoring\/controlling.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-3.jpg?v=1737701219\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eOne More Thing, Modbus Gateway\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eConnect to PLC, SCADA system or user’s private server to achieve local or remote motoring.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eModbus RTU to Modbus TCP\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eMulti-Host Modbus Polling\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-4.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eEdge Computing,\u003cbr\u003eEnabling Edge Device Connectivity in the IIOT Era\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eUSR-TCP232-410s can collected data in Modbus RTU, Modbus TCP protocol and reporting data to IoT cloud in JSON format using MQTT or TCP\/UDP\/HTTP protocol. It supports up to 128 data points, and can decode and compute the collected data to reduce server’s pressure.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-5.jpg?v=1737701227\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eCuston JSON\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eJSON message custom conversion\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eSupports protocol of various servers and can be used without complicated changes.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-6.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eData Transmission Encryption\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eSupports SSL\/TLS encryption in TCP client, HTTP client and MQTT operation modes.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eSupports two-way certificates authentication.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-7.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eOrdering Guide\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-8.jpg?v=1737701219\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eHigh Reliability Design\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eMetal Housing:\u003c\/strong\u003e effective cooling.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eWide Power Input: \u003c\/strong\u003eDC 9-36V, with reverse polarity protection.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eWide Operating Temp: \u003c\/strong\u003e-40℃ ~ +85℃, industrial grade design.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eHigh EMC Protection: \u003c\/strong\u003eensuring stable operation in harsh environments.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eWatchdog Protection:\u003c\/strong\u003e Hardware \u0026amp; software dual watchdog to ensure stable operation.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-9.jpg?v=1737701220\" alt=\"\"\u003e\u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eHardware Interface\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eSerial port: \u003c\/strong\u003eRS232 and RS485 serial ports can work simultaneously, the baud rate range is 600-230.4K (bps), and support hardware (CTS\/RTS) and software (XON\/XOFF) flow control.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eEthernet port:\u003c\/strong\u003e 10\/100M MDI\/MDIX, auto switch between cross and direct connection, 1.5KV electromagnetic isolation.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003ePower Supply: \u003c\/strong\u003eDC socket and terminal block connector.\u003cbr\u003eInstallation: Wall mounting.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eReload button:\u003c\/strong\u003e In the case of forgetting the parameters, long press to restore the factory settings.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-10.jpg?v=1737701220\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003ePacking List\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eUSR-TCP232-410s*1\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003ePower adapter*1\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eFemale-to-Female serial cable*1\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-11.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eApplication in Intelligent Electrical Fire\u003cbr\u003eWarning System\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eConnect fire alarm sensor to TCP232-410s via RS485\/232, and TCP232-410s can send the alarm information to the remote server to remind the staff to eliminate the fire.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-12.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eSmart Lighting Facilities in Factories and\u003cbr\u003eMines Monitoring\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eThe traditional lighting facilities in factories and mines are mostly controlling by people, and cannot realize linkage between manufacture and monitoring, and lead to energy wasting. USR-TCP232-410S communicates with serial lighting equipment via network, it is convenient for lighting control and can actively report the mistakes of the equipment.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-13.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eWater Service System Monitoring\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eFor now, the communication of water supply system in waterworks is still based on serial, and it is only suitable for single-machine operation and limited transmission distance, system maintenance is difficult. USR-TCP232-410s supports serial port to network, monitor the work of the equipment via TCP Server mode at any time.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-14.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003ePERIMETER\u003c\/h3\u003e\n\u003ctable border=\"1\"\u003e\n\u003cthead\u003e\n\u003ctr\u003e\n\u003cth style=\"text-align: center;\"\u003eModel\u003c\/th\u003e\n\u003cth style=\"text-align: center;\"\u003eUSR-TCP232-410s\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003c\/thead\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eProcessor\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eST Solution, Cortex-M7\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eFrequency\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e400MHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003ePower Supply\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eDC 5.0～36.0 V, 67mA @12V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eEthernet Port\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e1 x RJ45, 10 \/100 Mbps, auto MDI\/MDX, 1.5KV electromagnetic isolation\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eSerial Port\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e1 x RS232, DB9-male, 1 x RS485, 3-pin terminal block, can work simultaneously.\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eBaud rate\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e600 bps~230.4Kbps\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eData Bits\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e7, 8\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eStop Bit(s)\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e1, 2\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eParity Bit\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eNone, Even, Odd, Mark, Space\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eFlow Control\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eHardware: RTS\/CTS (Only RS232), Software：XON\/XOFF\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eDimensions(mm)\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e82.5*86*25mm(L*W*H)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eOperating Temperature\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e-40～85℃\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eStorage Temperature\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e-40~105℃\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eOperating Humidity\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e5%～95%（Non-condensing）\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eStorage Humidity\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e5%～95%（Non-condensing）\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eNetwork Protocol\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eIP, TCP, UDP, HTTP, MQTT, SSL\/TLS, ARP, ICMP, DHCP, DNS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eIP Assignment\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eStatic\/DHCP\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eDNS Service\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eBuilt-in Webpage\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eConfig Method\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eBuilt-in Webpage, Config Software, AT Command\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eWork Mode\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eTCP Server\/TCP client\/UDP Server\/UDP Client\/HTTPD client\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eEdge Computing\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√, up to 128 points\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eMQTT Gateway\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eStandard MQTT protocol\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eEncryption\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eMQTT+SSL, TCPC+SSL\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eModbus Gateway\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eModbus RTU\/TCP protocol conversion, Multi-host polling: up to 16 hosts\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eWebSocket\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eRF2217 Similar\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eRegistration Packet\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eHeartbeat Packet\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eSerial Packets Cache\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eDynamic packet cache. For example: When the packet length is 10 bytes, the serial port can cache 371 packets(3.71KB). When the packet length is 1460 bytes, the serial port can cache 10 packets(14.6KB).\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eEthernet Packets Cache\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e48KBytes\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eCertificate\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eCE, FCC, *RoHS, *WEEE\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eWarranty\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e2 years\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003ch3 style=\"text-align: center;\"\u003eDOWNLOAD\u003c\/h3\u003e\n\u003cp\u003e\u003cstrong\u003eDocuments\u003c\/strong\u003e\u003c\/p\u003e\n\u003ctable width=\"100%\" style=\"width: 100%; height: 164.75px;\"\u003e\n\u003ctbody\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e [User Manual]USR-TCP232-410s-User-Manual-V1.1.1.02\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/uploads\/20230925\/cc816d60345d688cbda902742c6aeafb.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 39.1875px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 39.1875px;\"\u003e[User Manual] USR-TCP232-410S Quick Start Guide\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 39.1875px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/M4\/USR-TCP232-410S%20Quick%20Start%20Guide.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 27.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 27.5938px;\"\u003e[Specification] USR-TCP232-410s Specification\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 27.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/uploads\/20241226\/705f1599042ace10c80fb176566cedf7.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Datasheet] USR-TCP232-410s Datasheet\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/datasheet\/USR-TCP232-410s_datasheet.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Certificate] USR-TCP232-410s KCC Certificate\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/Certificate\/USR-TCP232-410s_KCC_Certificate.zip\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Certificate] ROHS2.0-Certificates-For-Serial-Ethernet\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/ndirectory\/[Certificate]-ROHS2.0-Certificates-For-Serial-Etherent_1687230152.rar\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Certificate] M4 Series CE FCC ROHS WEEE Certificate\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/Certificate\/M4_Series_CE_FCC_ROHS_WEEE_Certificate.zip\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003cp\u003e\u003cstrong\u003eUtilities\u003c\/strong\u003e\u003c\/p\u003e\n\u003ctable style=\"width: 100%; height: 78.3752px;\" width=\"100%\"\u003e\n\u003ctbody\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Setup Software] H7 \/ RT Version\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/ndirectory\/[Setup-Software]-H7-Version_1687230153.rar\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[PC Test Software] USR-TCP232-Test-V1.3\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/M4\/USR-TCP232-Test-V1.3.exe\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Configuration Software]USR-TCP232-M4_V2.3.4.106\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/ndirectory\/[Configuration-Software]USR-TCP232-M4_V2.3.4.106_1687230152.exe\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Virtual COM Software]USR-VCOM_V5.0.4_Setup\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/uploads\/20241018\/c355c5f354ad1a86ced2533673251366.exe\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003cp\u003e\u003cstrong\u003eDevelopment Files\u003c\/strong\u003e\u003c\/p\u003e\n\u003ctable style=\"width: 100%; height: 39.1876px;\" width=\"100%\"\u003e\n\u003ctbody\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Socket_Demo] Socket_Demo.zip\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/ndirectory\/[Socket_Demo]-Socket_Demo.zip_1687230152.zip\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Config Protocol] E45\u0026amp;M4 Series Config Protocol V1.4\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/M4\/E45\u0026amp;M4%20config%20protocol%20V1.4.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003ch3 style=\"text-align: center;\"\u003eVIDEO\u003c\/h3\u003e\n\u003cp\u003e\u003ciframe title=\"How to use serial port to Ethernet server\" src=\"https:\/\/www.youtube.com\/embed\/lOupjTuQBA8\" height=\"624\" width=\"1110\"\u003e\u003c\/iframe\u003e\u003c\/p\u003e","published_at":"2025-02-10T15:54:23+05:30","created_at":"2025-01-24T12:20:47+05:30","vendor":"PUSR","type":"","tags":["AIoT","Automation","CloudConnectivity","CompactDesign","DataLogging","DataProcessing","DeviceIntegration","DINRailMount","EdgeComputing","EdgeGateway","EmbeddedNetworking","EmbeddedSystems","EnergySaving","EnvironmentalMonitoring","FailoverSupport","FirewallProtection","HighReliability","HighSpeedDataTransmission","HTTP","IND-IOT","IndustrialAutomation","IndustrialIoT","IndustrialNetworking","IntelligentLighting","IntelligentMonitoring","IoTConnectivity","IoTDeviceManagement","IPConfiguration","JSONSupport","ModbusGateway","ModbusRTU","ModbusTCP","MQTT","MQTTGateway","MultiClientAccess","MultiHostModbus","MultiProtocolSupport","PLCIntegration","PlugAndPlay","PointToPointCommunication","PowerControl","PowerEfficient","PUSR","PUSR IOT","RealTimeData","RemoteAccess","RemoteMonitoring","RS232","RS485","SCADA","SCADAIntegration","SecureCommunication","SecureDataTransmission","SecureIoT","SecureNetworking","SecureRemoteAccess","SecureSerialCommunication","SerialNetworking","SerialToEthernet","SmartFactory","SmartFireAlarm","SmartInfrastructure","SSL","TCP","TransparentTransmission","UDP","VirtualCOM","Watchdog","WaterSystemMonitoring","WebSocket","WideTemperature","WideVoltage","WLS-IOT"],"price":347999,"price_min":347999,"price_max":347999,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":49841376559421,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"ELC8530","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Serial to Ethernet - USR-TCP232-410s","public_title":null,"options":["Default Title"],"price":347999,"weight":800,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sa.png?v=1737703385","\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sb.png?v=1737703404","\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sc.png?v=1737703404","\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sd.png?v=1737703404","\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410se.png?v=1737703404"],"featured_image":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sa.png?v=1737703385","options":["Title"],"media":[{"alt":null,"id":42769040408893,"position":1,"preview_image":{"aspect_ratio":1.499,"height":373,"width":559,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sa.png?v=1737703385"},"aspect_ratio":1.499,"height":373,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sa.png?v=1737703385","width":559},{"alt":null,"id":42769042014525,"position":2,"preview_image":{"aspect_ratio":1.499,"height":373,"width":559,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sb.png?v=1737703404"},"aspect_ratio":1.499,"height":373,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sb.png?v=1737703404","width":559},{"alt":null,"id":42769042145597,"position":3,"preview_image":{"aspect_ratio":1.499,"height":373,"width":559,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sc.png?v=1737703404"},"aspect_ratio":1.499,"height":373,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sc.png?v=1737703404","width":559},{"alt":null,"id":42769042211133,"position":4,"preview_image":{"aspect_ratio":1.499,"height":373,"width":559,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sd.png?v=1737703404"},"aspect_ratio":1.499,"height":373,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410sd.png?v=1737703404","width":559},{"alt":null,"id":42769042276669,"position":5,"preview_image":{"aspect_ratio":1.499,"height":373,"width":559,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410se.png?v=1737703404"},"aspect_ratio":1.499,"height":373,"media_type":"image","src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/USR-TCP232-410se.png?v=1737703404","width":559},{"alt":null,"id":42769044111677,"position":6,"preview_image":{"aspect_ratio":1.333,"height":360,"width":480,"src":"\/\/thinkrobotics.com\/cdn\/shop\/files\/preview_images\/hqdefault_35f957a7-a073-4dcb-b2e8-d3ff48208c47.jpg?v=1737703421"},"aspect_ratio":1.77,"external_id":"lOupjTuQBA8","host":"youtube","media_type":"external_video"}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch1 style=\"text-align: center;\"\u003eUSR-TCP232-410s\u003c\/h1\u003e\n\u003ch3 style=\"text-align: center;\"\u003eRS232 and RS485 to Ethernet Converter\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eUSR-TCP232-410s is 2 serial Port Secure Serial Device Server which can connect RS-232\/485 serial devices to the TCP\/IP network. It supports bi-directional communication, edge computing, Modbus gateway, MQTT gateway and etc.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eUSR-TCP232-410s |Dual Ports Serial Device Server\u003c\/h3\u003e\n\u003ch4 style=\"text-align: center;\"\u003eRS485+RS232, MQTT+SSL, Modbus Gateway, Edge Computing\u003c\/h4\u003e\n\u003cp style=\"text-align: center;\"\u003eUSR-TCP232-410s is 2 serial Port Secure Serial Device Server which can connect 1*RS232 and 1*RS485 serial devices to the TCP\/IP network. It supports bi-directional communication, Modbus RTU\/TCP protocol conversion, edge computing and other advanced features. This product features for its Cortex-M7 core and the main frequency is up to 400MHz, which can ensure the high processing speed and stable data transmission.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-1.jpg?v=1737701220\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eKey Features\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003e1. \u003cstrong\u003eDual Serial Ports: \u003c\/strong\u003eRS485+RS232, can work simultaneously.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e2.\u003cstrong\u003e MQTT: \u003c\/strong\u003eCan connect to IoT platform with standard MQTT.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e3. \u003cstrong\u003eSSL Encryption: \u003c\/strong\u003eTo ensure data communication security.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e4.\u003cstrong\u003e Edge computing: \u003c\/strong\u003eUp to 300 points, reporting data in JSON format.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e5. \u003cstrong\u003eModbus Gateway: \u003c\/strong\u003eModbus TCP\/RTU protocol conversion.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e6.\u003cstrong\u003e Industrial Design: \u003c\/strong\u003e-40℃~+85℃, 5-36V DC power.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e7. \u003cstrong\u003eRich Protocol: \u003c\/strong\u003eTCP\/UDP\/MQTT\/HTTP.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e8. \u003cstrong\u003eUser-defined Webpage: \u003c\/strong\u003eUser can customize the webpage.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-2.jpg?v=1737701220\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eSerial to Ethernet,\u003cbr\u003eBidirectional Transparent Data Transmission\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eWith serial device server, traditional serial devices can be connected to local networks and the Internet, then users can transform traditional serial device into IOT device to achieve remote monitoring\/controlling.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-3.jpg?v=1737701219\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eOne More Thing, Modbus Gateway\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eConnect to PLC, SCADA system or user’s private server to achieve local or remote motoring.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eModbus RTU to Modbus TCP\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eMulti-Host Modbus Polling\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-4.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eEdge Computing,\u003cbr\u003eEnabling Edge Device Connectivity in the IIOT Era\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eUSR-TCP232-410s can collected data in Modbus RTU, Modbus TCP protocol and reporting data to IoT cloud in JSON format using MQTT or TCP\/UDP\/HTTP protocol. It supports up to 128 data points, and can decode and compute the collected data to reduce server’s pressure.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-5.jpg?v=1737701227\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eCuston JSON\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eJSON message custom conversion\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eSupports protocol of various servers and can be used without complicated changes.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-6.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eData Transmission Encryption\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eSupports SSL\/TLS encryption in TCP client, HTTP client and MQTT operation modes.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eSupports two-way certificates authentication.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-7.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eOrdering Guide\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-8.jpg?v=1737701219\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eHigh Reliability Design\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eMetal Housing:\u003c\/strong\u003e effective cooling.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eWide Power Input: \u003c\/strong\u003eDC 9-36V, with reverse polarity protection.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eWide Operating Temp: \u003c\/strong\u003e-40℃ ~ +85℃, industrial grade design.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eHigh EMC Protection: \u003c\/strong\u003eensuring stable operation in harsh environments.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eWatchdog Protection:\u003c\/strong\u003e Hardware \u0026amp; software dual watchdog to ensure stable operation.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-9.jpg?v=1737701220\" alt=\"\"\u003e\u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eHardware Interface\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eSerial port: \u003c\/strong\u003eRS232 and RS485 serial ports can work simultaneously, the baud rate range is 600-230.4K (bps), and support hardware (CTS\/RTS) and software (XON\/XOFF) flow control.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eEthernet port:\u003c\/strong\u003e 10\/100M MDI\/MDIX, auto switch between cross and direct connection, 1.5KV electromagnetic isolation.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003ePower Supply: \u003c\/strong\u003eDC socket and terminal block connector.\u003cbr\u003eInstallation: Wall mounting.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cstrong\u003eReload button:\u003c\/strong\u003e In the case of forgetting the parameters, long press to restore the factory settings.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-10.jpg?v=1737701220\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003ePacking List\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eUSR-TCP232-410s*1\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003ePower adapter*1\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003eFemale-to-Female serial cable*1\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-11.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eApplication in Intelligent Electrical Fire\u003cbr\u003eWarning System\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eConnect fire alarm sensor to TCP232-410s via RS485\/232, and TCP232-410s can send the alarm information to the remote server to remind the staff to eliminate the fire.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-12.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eSmart Lighting Facilities in Factories and\u003cbr\u003eMines Monitoring\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eThe traditional lighting facilities in factories and mines are mostly controlling by people, and cannot realize linkage between manufacture and monitoring, and lead to energy wasting. USR-TCP232-410S communicates with serial lighting equipment via network, it is convenient for lighting control and can actively report the mistakes of the equipment.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-13.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003eWater Service System Monitoring\u003c\/h3\u003e\n\u003cp style=\"text-align: center;\"\u003eFor now, the communication of water supply system in waterworks is still based on serial, and it is only suitable for single-machine operation and limited transmission distance, system maintenance is difficult. USR-TCP232-410s supports serial port to network, monitor the work of the equipment via TCP Server mode at any time.\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e\u003cimg src=\"https:\/\/cdn.shopify.com\/s\/files\/1\/0014\/4313\/5560\/files\/TCP232-410s-14.jpg?v=1737701226\" alt=\"\"\u003e\u003c\/p\u003e\n\u003cp style=\"text-align: center;\"\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003ePERIMETER\u003c\/h3\u003e\n\u003ctable border=\"1\"\u003e\n\u003cthead\u003e\n\u003ctr\u003e\n\u003cth style=\"text-align: center;\"\u003eModel\u003c\/th\u003e\n\u003cth style=\"text-align: center;\"\u003eUSR-TCP232-410s\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003c\/thead\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eProcessor\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eST Solution, Cortex-M7\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eFrequency\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e400MHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003ePower Supply\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eDC 5.0～36.0 V, 67mA @12V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eEthernet Port\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e1 x RJ45, 10 \/100 Mbps, auto MDI\/MDX, 1.5KV electromagnetic isolation\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eSerial Port\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e1 x RS232, DB9-male, 1 x RS485, 3-pin terminal block, can work simultaneously.\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eBaud rate\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e600 bps~230.4Kbps\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eData Bits\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e7, 8\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eStop Bit(s)\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e1, 2\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eParity Bit\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eNone, Even, Odd, Mark, Space\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eFlow Control\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eHardware: RTS\/CTS (Only RS232), Software：XON\/XOFF\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eDimensions(mm)\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e82.5*86*25mm(L*W*H)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eOperating Temperature\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e-40～85℃\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eStorage Temperature\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e-40~105℃\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eOperating Humidity\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e5%～95%（Non-condensing）\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eStorage Humidity\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e5%～95%（Non-condensing）\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eNetwork Protocol\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eIP, TCP, UDP, HTTP, MQTT, SSL\/TLS, ARP, ICMP, DHCP, DNS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eIP Assignment\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eStatic\/DHCP\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eDNS Service\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eBuilt-in Webpage\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eConfig Method\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eBuilt-in Webpage, Config Software, AT Command\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eWork Mode\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eTCP Server\/TCP client\/UDP Server\/UDP Client\/HTTPD client\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eEdge Computing\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√, up to 128 points\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eMQTT Gateway\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eStandard MQTT protocol\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eEncryption\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eMQTT+SSL, TCPC+SSL\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eModbus Gateway\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eModbus RTU\/TCP protocol conversion, Multi-host polling: up to 16 hosts\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eWebSocket\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eRF2217 Similar\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eRegistration Packet\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eHeartbeat Packet\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e√\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eSerial Packets Cache\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eDynamic packet cache. For example: When the packet length is 10 bytes, the serial port can cache 371 packets(3.71KB). When the packet length is 1460 bytes, the serial port can cache 10 packets(14.6KB).\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eEthernet Packets Cache\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e48KBytes\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eCertificate\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003eCE, FCC, *RoHS, *WEEE\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd style=\"text-align: center;\"\u003eWarranty\u003c\/td\u003e\n\u003ctd style=\"text-align: center;\"\u003e2 years\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003ch3 style=\"text-align: center;\"\u003eDOWNLOAD\u003c\/h3\u003e\n\u003cp\u003e\u003cstrong\u003eDocuments\u003c\/strong\u003e\u003c\/p\u003e\n\u003ctable width=\"100%\" style=\"width: 100%; height: 164.75px;\"\u003e\n\u003ctbody\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e [User Manual]USR-TCP232-410s-User-Manual-V1.1.1.02\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/uploads\/20230925\/cc816d60345d688cbda902742c6aeafb.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 39.1875px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 39.1875px;\"\u003e[User Manual] USR-TCP232-410S Quick Start Guide\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 39.1875px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/M4\/USR-TCP232-410S%20Quick%20Start%20Guide.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 27.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 27.5938px;\"\u003e[Specification] USR-TCP232-410s Specification\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 27.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/uploads\/20241226\/705f1599042ace10c80fb176566cedf7.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Datasheet] USR-TCP232-410s Datasheet\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/datasheet\/USR-TCP232-410s_datasheet.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Certificate] USR-TCP232-410s KCC Certificate\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/Certificate\/USR-TCP232-410s_KCC_Certificate.zip\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Certificate] ROHS2.0-Certificates-For-Serial-Ethernet\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/ndirectory\/[Certificate]-ROHS2.0-Certificates-For-Serial-Etherent_1687230152.rar\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Certificate] M4 Series CE FCC ROHS WEEE Certificate\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/Certificate\/M4_Series_CE_FCC_ROHS_WEEE_Certificate.zip\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003cp\u003e\u003cstrong\u003eUtilities\u003c\/strong\u003e\u003c\/p\u003e\n\u003ctable style=\"width: 100%; height: 78.3752px;\" width=\"100%\"\u003e\n\u003ctbody\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Setup Software] H7 \/ RT Version\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/ndirectory\/[Setup-Software]-H7-Version_1687230153.rar\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[PC Test Software] USR-TCP232-Test-V1.3\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/M4\/USR-TCP232-Test-V1.3.exe\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Configuration Software]USR-TCP232-M4_V2.3.4.106\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/ndirectory\/[Configuration-Software]USR-TCP232-M4_V2.3.4.106_1687230152.exe\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Virtual COM Software]USR-VCOM_V5.0.4_Setup\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; height: 19.5938px; text-align: right;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/uploads\/20241018\/c355c5f354ad1a86ced2533673251366.exe\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003cp\u003e\u003cstrong\u003eDevelopment Files\u003c\/strong\u003e\u003c\/p\u003e\n\u003ctable style=\"width: 100%; height: 39.1876px;\" width=\"100%\"\u003e\n\u003ctbody\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Socket_Demo] Socket_Demo.zip\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/ndirectory\/[Socket_Demo]-Socket_Demo.zip_1687230152.zip\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr style=\"height: 19.5938px;\"\u003e\n\u003ctd style=\"width: 65.9926%; height: 19.5938px;\"\u003e[Config Protocol] E45\u0026amp;M4 Series Config Protocol V1.4\u003c\/td\u003e\n\u003ctd style=\"width: 33.6397%; text-align: right; height: 19.5938px;\"\u003e\u003ca href=\"https:\/\/www.pusr.com\/download\/M4\/E45\u0026amp;M4%20config%20protocol%20V1.4.pdf\"\u003eDownload \u0026gt;\u0026gt;\u003c\/a\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003ch3 style=\"text-align: center;\"\u003e\u003cbr\u003e\u003c\/h3\u003e\n\u003ch3 style=\"text-align: center;\"\u003eVIDEO\u003c\/h3\u003e\n\u003cp\u003e\u003ciframe title=\"How to use serial port to Ethernet server\" src=\"https:\/\/www.youtube.com\/embed\/lOupjTuQBA8\" height=\"624\" width=\"1110\"\u003e\u003c\/iframe\u003e\u003c\/p\u003e"}

[Setup Software] H7 / RT Version	Download >>
[PC Test Software] USR-TCP232-Test-V1.3	Download >>
[Configuration Software]USR-TCP232-M4_V2.3.4.106	Download >>
[Virtual COM Software]USR-VCOM_V5.0.4_Setup	Download >>

[Socket_Demo] Socket_Demo.zip	Download >>
[Config Protocol] E45&M4 Series Config Protocol V1.4	Download >>

Serial to Ethernet - USR-TCP232-410s

USR-TCP232-410s

RS232 and RS485 to Ethernet Converter

USR-TCP232-410s |Dual Ports Serial Device Server

RS485+RS232, MQTT+SSL, Modbus Gateway, Edge Computing

Key Features

Serial to Ethernet,
Bidirectional Transparent Data Transmission

One More Thing, Modbus Gateway

Edge Computing,
Enabling Edge Device Connectivity in the IIOT Era

Custon JSON

Data Transmission Encryption

Ordering Guide

High Reliability Design

Hardware Interface

Packing List

Application in Intelligent Electrical Fire
Warning System

Smart Lighting Facilities in Factories and
Mines Monitoring

Water Service System Monitoring

PERIMETER

DOWNLOAD

VIDEO

Want to buy in bulk?

Customer Reviews

Custom Requirements?

Download the ThinkRobotics Mobile App

We are here to serve you! Reach us at:

Popular Links

Shopping Cart

Let customers speak for us

Model	USR-TCP232-410s
Processor	ST Solution, Cortex-M7
Frequency	400MHz
Power Supply	DC 5.0～36.0 V, 67mA @12V
Ethernet Port	1 x RJ45, 10 /100 Mbps, auto MDI/MDX, 1.5KV electromagnetic isolation
Serial Port	1 x RS232, DB9-male, 1 x RS485, 3-pin terminal block, can work simultaneously.
Baud rate	600 bps~230.4Kbps
Data Bits	7, 8
Stop Bit(s)	1, 2
Parity Bit	None, Even, Odd, Mark, Space
Flow Control	Hardware: RTS/CTS (Only RS232), Software：XON/XOFF
Dimensions(mm)	82.58625mm(LWH)
Operating Temperature	-40～85℃
Storage Temperature	-40~105℃
Operating Humidity	5%～95%（Non-condensing）
Storage Humidity	5%～95%（Non-condensing）
Network Protocol	IP, TCP, UDP, HTTP, MQTT, SSL/TLS, ARP, ICMP, DHCP, DNS
IP Assignment	Static/DHCP
DNS Service	√
Built-in Webpage	√
Config Method	Built-in Webpage, Config Software, AT Command
Work Mode	TCP Server/TCP client/UDP Server/UDP Client/HTTPD client
Edge Computing	√, up to 128 points
MQTT Gateway	Standard MQTT protocol
Encryption	MQTT+SSL, TCPC+SSL
Modbus Gateway	Modbus RTU/TCP protocol conversion, Multi-host polling: up to 16 hosts
WebSocket	√
RF2217 Similar	√
Registration Packet	√
Heartbeat Packet	√
Serial Packets Cache	Dynamic packet cache. For example: When the packet length is 10 bytes, the serial port can cache 371 packets(3.71KB). When the packet length is 1460 bytes, the serial port can cache 10 packets(14.6KB).
Ethernet Packets Cache	48KBytes
Certificate	CE, FCC, RoHS, WEEE
Warranty	2 years

[User Manual]USR-TCP232-410s-User-Manual-V1.1.1.02	Download >>
[User Manual] USR-TCP232-410S Quick Start Guide	Download >>
[Specification] USR-TCP232-410s Specification	Download >>
[Datasheet] USR-TCP232-410s Datasheet	Download >>
[Certificate] USR-TCP232-410s KCC Certificate	Download >>
[Certificate] ROHS2.0-Certificates-For-Serial-Ethernet	Download >>
[Certificate] M4 Series CE FCC ROHS WEEE Certificate	Download >>
