Package includes multiple connectors with integral spacers and captive hardware for efficient assembly
Recognized by Underwriters' Laboratories to US and Canadian standards (file No. E28476)
Technical Specifications
Performance Characteristics
Electrical Resistance
Maximum 10 milliohms (D R)
Insulation Resistance
Minimum 1000 megohms
Dielectric Withstanding Voltage
500 VAC for 1 minute at sea level
Mechanical Characteristics
Current
Signal application only
Operating Temperature Range
–55°C to 105°C
Material & Finish
Housing
Black Thermoplastic, UL 94V-0
Contact Material
Phosphor Bronze, Full Gold over Nickel (stackthrough), Gold on mating end, Tin or Tin-lead on PCB tail over Nickel (non-stackthrough)
Connector Details
Centerline Positions: .100 [2.54]
Designed for PC/104 and PC/104-Plus standards
Press-fit design eliminates hand soldering
Unitized assembly reduces inventory complexity
Integral board spacers with captive hardware streamline assembly
Compatible with lead-free processes such as ENIG and silver immersion plating
Additional Information
This product is suitable for high-density, reliable interconnections in industrial applications. The connectors are designed for ease of installation and compliance with industry standards. For more detailed technical data, please refer to the full datasheet.
Note: Datasheet was not processed, please search the internet for the part number for more details.
