The TE CONNECTIVITY / RAYCHEM RAY PRC: RAY Part Number 504284003 is a high-quality wire and cable management solution designed for reliable electrical insulation and protection. This product falls under the category of Heat Shrink Tubing and Sleeves, ensuring secure and durable cable insulation in various applications.
This wire and cable management product is compliant with multiple standards including EU RoHS Directive 2011/65/EU, EU ELV Directive 2000/53/EC, and China RoHS 2 Directive. It is designed to meet Mil-Spec M23053/16-001-0, ensuring high durability and performance in demanding environments.
It is suitable for applications requiring reliable insulation, environmental protection, and strain relief for electrical wiring systems.
This information is provided based on reasonable inquiry of our suppliers and represents our current actual knowledge based on the information they provided. This information is subject to change. The part numbers that TE has identified as EU RoHS compliant have a maximum concentration of 0.1% by weight in homogenous materials for lead, hexavalent chromium, mercury, PBB, PBDE, DBP, BBP, DEHP, DIBP, and 0.01% for cadmium, or qualify for an exemption to these limits as defined in the Annexes of Directive 2011/65/EU (RoHS2). Finished electrical and electronic equipment products will be CE marked as required by Directive 2011/65/EU. Components may not be CE marked. Additionally, the part numbers that TE has identified as EU ELV compliant have a maximum concentration of 0.1% by weight in homogenous materials for lead, hexavalent chromium, and mercury, and 0.01% for cadmium, or qualify for an exemption to these limits as defined in the Annexes of Directive 2000/53/EC (ELV). Regarding the REACH Regulation, the information TE provides on SVHC in articles for this part number is based on the latest European Chemicals Agency (ECHA) ‘Guidance on requirements for substances in articles’ posted at ECHA Guidance.
Datasheet was not processed please search the internet for the part number for more details.
Note: The product image displayed is a standard reference image. Actual product appearance may vary. For the most accurate and up-to-date representation, we recommend searching the part number online.
