The APM2.5 UBlox NEO-M7N GPS Module GYGPSV1-7M is optimized for cost-sensitive applications, while NEO-M7N/M7Q provides the best performance and easier RF integration. The NEO-M7N offers high performance also at low power consumption levels. The future-proof NEO-M7N includes an internal Flash that allows future firmware updates. This makes NEO-M7N perfectly suited to industrial and automotive applications.
The NEO-M7 series of concurrent GNSS modules are built on the high performing u-Blox M7 GNSS engine in the industry proven NEO form factor.NEO-M7N provides the best performance and easier RF integration. The NEO-M7N offers high performance also at low power consumption levels. The future-proof NEOM7N includes an internal Flash that allows future firmware updates. This makes NEO-M7N perfectly suited to industrial and automotive applications.
Specifications
- Receiver type 72-channel M7 engine
- GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1
- SBAS L1 C/A: WAAS, EGNOS, MSAS
- Galileo-ready E1B/C
- Nav. update rate1 Single GNSS: up to 18 HZ
- Concurrent GNSS: up to 10 Hz
- Position accuracy2 2.0 m CEP
- Acquisition2 Cold starts: 26 s
- Aided starts: 2 s
- Reacquisition: 1.5 s
- Sensitivity2 Tracking & Nav: -167 dBm
- Cold starts: -148 dBm
- Hot starts: -156 dBm
- Assistance AssistNow GNSS Online
- AssistNow GNSS Offline (up to 35 days)3
- AssistNow Autonomous (up to 6 days)
- OMA SUPL & 3GPP compliant
- Supply voltage 1.65 V to 3.6 V
- 2.7 V to 3.6 V
- Power consumption4 23 mA @ 3.0 V (continuous)
- 5 mA @ 3.0 V Power Save Mode
- (1 Hz, GPS mode only)
- Backup Supply 1.4 to 3.6 V
- Concurrent GNSS LCC Module,
- TCXO, flash, SAW, LNA,
- Timepulse Configurable 0.25 Hz to 10 MHz
