Core51822 is a wireless module based on nRF51822 - the Multiprotocol Bluetooth® 4.0 low energy/2.4 GHz RF SoC designed for ULP (ultra low power) wirelesss applications.
Overview
Core51822 is a wireless module based on nRF51822-the low-power Bluetooth® 4.0 Multiprotocol / 2.4 GHz RF soC designed for ULP (ultra low power) wireless applications.
Core51822 Specifications
On board the chip: nRF51822
Communication distance (external open @ 1 M data rate): 30 m
Frequency range: 2.4 GHz
Operating voltage: 2.0 V ~ 3.6 V
Operating temperature: -40 ° ~ 85 °
Dimensions (PCB): 20.3 mm x 15.50 mm
Expansion pinheader: all the I / Os except P0.26 and P0.27
Pinheader pitch: 2.00 mm
Spacing between pinheaders on the left side and right side: 18.00 mm
Antenna: antenna on board
NRF51822 Feature
2.4 GHz multiprotocol RF transceiver
128-bit AES HW encryption
256kB flash & 16kB of RAM
Programmable Peripheral Interconnection (PPI)
Digital interfaces: SPI, I2C, UART
10 bit ADC
Programmable output power: -20 to + 4 dBm
The development of independent applications and protocol stacks
