- Temperature range: -50-110 °
- Dimensions: 48.5 * 40mm
- Temperature control mode: ON / OFF
- Resolution: When temperature is 0.1°, the resolution is -9.9~99.9, other temperature segment is 1°
- Control accuracy: 0.1°
- Display accuracy: 0.1°
- Refresh rate: 0.5 S
- High temperature protection: 0-110°
- Supply voltage: DC 12V
- Static current: ≤ 35MA, attract current ≤ 65MA
- Output voltage: DC 12V
- Output power: 20A relay
- Measurement input: NTC (10K 0.5%) Waterproof Sensor
- Environmental requirements: -10 ~ 60 ° ,Humidity 20% -85%
