The Jetson Orin 5G AI Deployment Kit combines the powerful NVIDIA Jetson Orin™ NX Orin™ Nano module with the versatile A608 carrier board and the high-performance RM520N-GL 5G module. This platform is designed for advanced edge AI applications requiring ultra-low latency connectivity, making it ideal for robotics, autonomous systems, UAVs, industrial automation, and next-generation AIoT deployments.
| High-Performance Edge AI Platform | Built on NVIDIA Jetson Orin™ NX / Orin™ Nano modules delivering powerful GPU-accelerated computing for computer vision, robotics, AI inference, and generative AI workloads. |
| Integrated 5G Connectivity | Equipped with the RM520N-GL 5G module based on Qualcomm Snapdragon X62 platform supporting 5G SA and NSA networking for ultra-fast wireless communication. |
| Multi-Mode Global Network Support | Compatible with 5G, LTE, and WCDMA networks with support for multiple global frequency bands ensuring reliable connectivity across regions. |
| High-Speed USB 3.1 Interface | Provides high-bandwidth USB connectivity between the Jetson system and the 5G modem for ultra-low latency networking and high-speed data transfer. |
| Dual Gigabit Ethernet | Two onboard Gigabit Ethernet ports allow high-speed wired networking for industrial deployments and AI edge servers. |
| Flexible Wireless Expansion | M.2 KEY B slot enables integration of 4G/5G modules while M.2 KEY E supports WiFi expansion, providing flexible connectivity options. |
| Quad Antenna Design | Four SMA antenna connectors ensure strong signal reception and stable high-speed wireless communication. |
| Multi-Constellation GNSS Positioning | Supports GPS, GLONASS, Beidou, Galileo, and QZSS for high-precision positioning and navigation applications. |
| Rich IO for Robotics and Embedded Systems | Includes CAN, I2C, SPI, UART, CSI camera interfaces, and multiple GPIOs for easy integration with sensors, cameras, and robotic subsystems. |
| Wide Power Input Range | Operates from 9V to 20V DC with up to 60W power input, making it suitable for mobile robots, drones, and industrial environments. |
The Jetson Orin 5G Deployment Kit is designed to deliver powerful AI computing combined with next-generation wireless connectivity. By integrating NVIDIA's edge AI platform with the RM520N-GL 5G modem, the system enables real-time cloud connectivity, remote AI processing, and high-speed data streaming for intelligent edge applications.
The A608 carrier board provides a wide range of interfaces including dual Gigabit Ethernet, USB 3.2, CSI camera ports, CAN bus, and multiple expansion connectors, making it an ideal development platform for autonomous robots, AI surveillance systems, drones, and smart industrial devices.
With multi-constellation GNSS positioning and ultra-fast 5G connectivity, this platform is perfectly suited for applications requiring real-time telemetry, remote monitoring, edge analytics, and AI-powered automation.
* Note: The frequency band diagram above is for reference only,
please confirm the supported bands according to your local service provider.
| Autonomous Robots |
| Industrial AI & Automation |
| Unmanned Aerial Vehicles (UAVs) |
| Edge AI Video Analytics |
| Smart Cities & Intelligent Transportation |
| Remote Monitoring Systems |
| AIoT Devices |
| Autonomous Marine Vehicles |
| Product Name | Jetson Orin 5G AI Deployment Kit |
| AI Module Compatibility | NVIDIA Jetson Orin™ NX / Orin™ Nano |
| Carrier Board | A608 Jetson Carrier Board |
| 5G Module | RM520N-GL (Qualcomm Snapdragon X62 Platform) |
| 5G Network | 5G SA / NSA |
| Networking | 2 × Gigabit Ethernet |
| USB | 4 × USB 3.2 Type-A, 1 × USB Type-C |
| Camera | 2 × 4-lane MIPI CSI |
| Wireless | 5G via M.2 KEY B, WiFi via M.2 KEY E |
| Storage | M.2 KEY M NVMe SSD Support |
| GNSS | GPS / GLONASS / Beidou / Galileo / QZSS |
| Power Input | 9V – 20V DC (Max 60W) |
| Operating Temperature | -25°C to +65°C |
| Antenna Connectors | 4 × SMA |
| A608 Carrier Board for Jetson Orin™ NX / Orin™ Nano | x1 |
| Jetson Orin NX / Orin Nano Module OPTIONS | x1 |
| Cooling Fan / Heatsink | x1 |
| 240GB NVMe SSD | x1 |
| RM530N-GL 5G Module | x1 |
| 5G Antennas | x4 |
| Power Supply | x1 |
| Aluminium Case / Enclosure | x1 |
