XM1584 Ultra-Small Size DC-DC Step Down Module
Features:
Input Voltage : 4.5~28V Output voltage : 0.8V~20V Output Current : 3A(Max) Efficiency : 92%(Max) Switch Frequency : 1.5MHz(Max),1MHz(Typ) Operating Temperature : -20 to +85
Specifications
Resources Datasheet
Tutorial VIDEO VIDEO
