Description
RUT951 features dual-SIM cellular connectivity combined with Wi-Fi and four Ethernet interfaces to meet the needs of the most varied IoT scenarios. Powered by RutOS, this router offers advanced customization options, automation features, and top-level security for your solution.
Standard package*
- Router RUT951
- 9 W PSU
- 2x Mobile antennas (swivel, SMA male)
- 2x Wi-Fi antennas (swivel, RP-SMA male)
- Ethernet cable (1.5 m)
- SIM Adapter kit
- QSG (Quick Start Guide)
- Packaging box
*Standard package contents may differ based on standard order codes.
Features
Mobile
| Category | Details |
|---|---|
| Mobile Module | 4G LTE Cat 4 up to 150 DL/50 UL Mbps; 3G up to 21 DL/5.76 UL Mbps; 2G up to 236.8 DL/236.8 UL kbps |
| 3GPP Release | Release 10/11 depending on the hardware version |
| SIM Switch | 2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection |
| Status | IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC |
| SMS | SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP |
| USSD | Supports sending and reading Unstructured Supplementary Service Data messages |
| Black/White List | Operator black/white list (by country or separate operators) |
| Multiple PDN | Possibility to use different PDNs for multiple network access and services |
| Band Management | Band lock, Used band status display |
| SIM PIN Code Management | SIM PIN code management enables setting, changing, or disabling the SIM card's PIN |
| APN | Auto APN |
| Bridge | Direct connection (bridge) between mobile ISP and device on LAN |
| Passthrough | Router assigns its mobile WAN IP address to another device on LAN |
Wireless
| Category | Details |
|---|---|
| Wireless Mode | 802.11b/g/n (Wi-Fi 4), Access Point (AP), Station (STA) |
| Wi-Fi Security | WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, disable auto-reconnect, 802.11w Protected Management Frames (PMF) |
| SSID/ESSID | SSID stealth mode and access control based on MAC address |
| Wi-Fi Users | Up to 100 simultaneous connections |
| Wireless Connectivity Features | Fast roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource measurement (802.11k) |
| Wireless MAC Filter | Allowlist, blocklist |
| Wireless QR Code Generator | Once scanned, a user will automatically enter your network without needing to input login information |
| TravelMate | Forward Wi-Fi hotspot landing page to a subsequent connected device |
Ethernet
| Category | Details |
|---|---|
| WAN | 1 x WAN port 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX |
| LAN | 3 x LAN ports, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX |
Network
| Category | Details |
|---|---|
| Routing | Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy-based routing |
| Network Protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN |
| VoIP Passthrough Support | H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
| Connection Monitoring | Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection |
| Firewall | Port forward, traffic rules, custom rules, TTL target customisation |
| Firewall Status Page | View all your Firewall statistics, rules, and rule counters |
| Ports Management | View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and more |
| Network Topology | Visual representation of your network, showing which devices are connected to which other devices |
| Hotspot | Captive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customisable themes, optionality to upload/download customised hotspot themes |
| DHCP | Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards |
| QoS / SQM | Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e |
| DDNS | Supported by over 25 service providers, others can be configured manually |
| DNS Over HTTPS | DNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS |
| Network Backup | Wi-Fi WAN, Mobile, VRRP, Wired options, each of which can be used as an automatic Failover |
| Load Balancing | Balance Internet traffic over multiple WAN connections |
| SSHFS | Possibility to mount remote file system via SSH protocol |
| Traffic Management | Real-time monitoring, wireless signal charts, traffic usage history |
| Port Mirroring | Mirroring network traffic on Ethernet ports for monitoring and analysis |
Security
| Category | Details |
|---|---|
| Authentication | Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator |
| Firewall | Preconfigured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64 |
| Attack Prevention | DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) |
| VLAN | Port and tag-based VLAN separation |
| Mobile Quota Control | Mobile data limit, customizable period, start time, warning limit, phone number |
| WEB Filter | Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only |
| Access Control | Flexible access control of SSH, Web interface, CLI, and Telnet |
| SSL Certificate Generation | Let's Encrypt and SCEP certificate generation methods |
VPN Features
| Protocol | Details |
|---|---|
| OpenVPN | Supports multiple clients and server instances running simultaneously; offers 27 encryption methods. |
| OpenVPN Encryption | Encryption methods include DES-CBC 64, RC2-CBC 128, AES-128-CBC, AES-256-GCM 256, and more, supporting bit lengths of 40 to 256 for enhanced security. |
| IPsec | Includes XFRM, IKEv1, and IKEv2 with 14 encryption methods (e.g., 3DES, DES, AES128, AES256, AES128GCM16). |
| GRE | GRE tunnels supported, including GRE over IPsec. |
| PPTP / L2TP | Both Client and Server modes supported, along with L2TPv3 and L2TP over IPsec. |
| Stunnel | Adds TLS encryption functionality to existing clients and servers without modifying the program's code. |
| DMVPN | Supports Dynamic Multipoint VPN with Phase 2, Phase 3, and Dual Hub configurations for scalable IPsec VPNs. |
| SSTP | Secure Socket Tunneling Protocol (SSTP) client instance supported. |
| ZeroTier | ZeroTier VPN client support for secure, simple, and scalable VPN setups. |
| WireGuard | Supports WireGuard VPN as both client and server, known for its high-speed and modern cryptographic protocols. |
| Tinc | Tinc VPN provides encryption, authentication, and compression in tunnels, with both client and server functionality. |
OPC UA Features
| Feature | Details |
|---|---|
| Supported Modes | Client, Server |
| Supported Connection | TCP |
MODBUS Features
| Feature | Details |
|---|---|
| Supported Modes | Server, Client |
| Supported Connection | TCP |
| Custom Registers | MODBUS TCP custom register block requests to read/write files within the router, extending MODBUS TCP Client functionality. |
| Supported Data Formats |
8-bit: INT, UINT 16-bit: INT, UINT (MSB or LSB first) 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII |
Data to Server Features
| Feature | Details |
|---|---|
| Supported Protocols | HTTP(S), MQTT, Azure MQTT, Kinesis |
| Functionality | Extract parameters from various sources and protocols to send consolidated data to a single server. |
| Customization | Support for custom LUA scripting, enabling scripts to leverage the router's Data to Server feature for automation and flexibility. |
MQTT Gateway Features
| Feature | Details |
|---|---|
| Modbus MQTT Gateway | Enables communication with a MODBUS Server through an MQTT broker. |
| Functionality | - Send commands to the MODBUS Server. - Receive data from the MODBUS Server via MQTT. |
DNP3 Protocol Features
| Feature | Details |
|---|---|
| Supported Modes | Station, Outstation |
| Supported Connection | TCP |
DLMS Protocol Features
| Feature | Details |
|---|---|
| DLMS Support | DLMS - standard protocol for utility meter data exchange |
| Supported Modes | Client |
| Supported Connection Types | TCP |
| COSEM | Allows scanning meter COSEM objects for automatic detection and configuration |
API Features
| Feature | Details |
|---|---|
| Teltonika Networks Web API (beta) support | Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to documentation |
Monitoring & Management
| Feature | Details |
|---|---|
| WEB UI | HTTP/HTTPS, provides status, configuration, firmware update, CLI, troubleshoot, event log servers, notifications, system and kernel logs, internet status. |
| FOTA | Firmware update from server, automatic notifications for updates. |
| SSH | Secure SSH (v1, v2) access for remote management. |
| SMS | SMS status and configuration; send/read SMS via HTTP POST/GET. |
| Call | Allows mobile data on/off, reboot, status checks, output control, answer/hang-up calls, Wi-Fi control. |
| TR-069 | Compatibility with ACS providers like OpenACS, EasyCwmp, LibreACS, GenieACS, FreeACS, and others. |
| MQTT | MQTT Broker and publisher for remote monitoring and data exchange. |
| SNMP | Supports SNMP (v1, v2, v3), SNMP Trap with brute force protection. |
| JSON-RPC | Management API over HTTP/HTTPS for advanced device management. |
| RMS | Teltonika Remote Management System for centralized management and monitoring. |
IoT Platforms
| Platform | Details |
|---|---|
| ThingWorx | Monitors WAN Type, WAN IP, Mobile Operator, Signal Strength, Network Type. |
| Cumulocity - Cloud of Things | Allows monitoring of device details (Model, Revision, Serial Number), WAN info, signal strength, and more. Offers reboot and firmware actions. |
| Azure IoT Hub | Configurable with Data to Server to send parameters to the cloud. Offers Direct method support and Plug and Play integration for zero-touch provisioning. |
| AWS IoT Core | Interacts with AWS cloud platform, supports calling the device's API using AWS Jobs functionality. |
