TE CONNECTIVITY/AMP BRAND 5-747904-8 D-Sub Standard Connector, 9-Pin, Solder Cup
The TE CONNECTIVITY/AMP BRAND 5-747904-8 is a high-quality, 9-position D-shaped connector designed for reliable signal transmission in electronic applications. Manufactured in China (COO: CN), this connector is part of TE's Data and Devices business unit and is supplied in a tray packaging for easy handling and installation.
Product Features
Connector Type: D-Shaped Plug
Number of Positions: 9
Connector & Housing Type: Plug
System: Cable-to-Board
Mounting Type: Cable Mount (Free-Hanging)
Shell Size: 1
Centerline (Pitch): 2.79 mm [.11 in]
Shell Material: Steel with Tin Plating
Contact Type: Pin
Contact Material: Phosphor Bronze with Nickel Underplating and Gold Flash on Mating Area
Wire & Cable Compatibility: 20 AWG
Operating Temperature Range: -55°C to 105°C
Sealable: No
RoHS & EU Compliance: Yes
Package Type: Tray
ECCN: EAR99
Specifications
Feature
Details
Contact Size
Size 20, 0.8 µin Nickel Plating
Current Rating (Max)
3 A
Wire Size
20 AWG
Usage Conditions
Operating Temperature: -55°C to 105°C
Standards & Compliance
UL Flammability Rating: UL 94V-0; RoHS & EU ELV Compliant
