Introducing the MOLEX 53047-0510, a high-quality connector designed for reliable electrical connections in various electronic applications. Manufactured in Japan, this vertical header features a 5-position configuration, ensuring secure and efficient signal transmission.
Part Number: 53047-0510
Manufacturer: MOLEX
Country of Origin (COO): JP (Japan)
Unit of Measure (UOM): EA (Each)
ECCN: EAR99
Package Type: TRAY
RoHS Compliant: Yes
Product Features
Vertical header configuration for space-efficient PCB mounting
5-position pin layout suitable for signal and power connections
Designed for robust electrical connections in power and signal applications
Compatible with a variety of wire sizes and types
Part of Molex's extensive range of industrial and electronic connectors
For more detailed specifications and technical information, please refer to the datasheet linked above. The datasheet provides comprehensive details on dimensions, mating specifications, and wiring options.
Note: This part is not formally published to the online part catalog. Limited information is available. Please search the internet for the part number 53047-0510 for additional details.
