TE CONNECTIVITY/AMP BRAND AMP PRC: AMP Part Number: 6-535542-5
Designed for reliable electrical connections, the Headers & Wire Housings 30 MODIV VRT DR CE 100/130 from TE Connectivity/AMP Brand offers high-quality performance in industrial applications. Manufactured in the USA, this connector complies with RoHS standards and is available in a convenient tube package. The product's detailed specifications and technical data can be found in the datasheet.
Product Features
Dual Entry, End Stackable, Low Profile design with .100 x .100 [2.54 x 2.54] centerline and .200 [5.08] tine spacing
Housing made of glass-filled thermoplastic, black, 94V-0 rated for durability and safety
Contacts made of phosphor bronze with multiple plating options for reliable mating:
Plating A: Duplex .000030 [0.00076] gold on contact area, matte tin on solder area, nickel all over
Plating B: Duplex .000010 [0.000254] gold on contact area, matte tin on solder area, nickel all over
Plating C: .000150-.000300 [0.00381-0.00762] matte tin on solder leads, nickel all over
High-performance contact design with dual cantilever beams for reliable connections
Surface mount vertical receptacle assemblies suitable for IR or vapor-phase reflow processes
Metallic hold downs for retention and strain relief during soldering and mating
Lead-in ramp for positive mating, minimizing stubbing risk
RoHS compliant and recognized under UL Component Program
Technical Specifications
Part Number
Number of Positions
Dimensions (A x B)
Plating A
Plating B
Plating C
6-535542-1
2
.100 [2.54]
5-147095-1
5-147096-1
7-535542-1
6-535542-2
4
.200 [5.08]
5-147095-2
5-147096-2
7-535542-2
6-535542-3
6
.300 [7.62]
5-147095-3
5-147096-3
7-535542-3
6-535542-4
8
.400 [10.16]
5-147095-4
5-147096-4
7-535542-4
6-535542-5
10
.500 [12.70]
5-147095-5
5-147096-5
7-535542-5
6-535542-6
12
.600 [15.24]
5-147095-6
5-147096-6
8-535542-6
6-535542-7
14
.700 [17.78]
5-147095-7
5-147096-7
8-535542-7
6-535542-8
16
.800 [20.32]
5-147095-8
5-147096-8
8-535542-8
6-535542-9
18
.900 [22.86]
5-147095-9
5-147096-9
8-535542-9
6-535542-0
20
1.000 [25.40]
6-147095-0
6-147096-0
9-535542-0
Additional Details
Package Type: TUBE
UOM: EA
ECCN: EAR99
RoHS: Yes
For more detailed specifications and technical data, please refer to the datasheet.
