MOLEX SAS/PCIE Recpt RA SMT 0.76AuLF 68ckt - Part Number: 78800-0001
Enhance your electronic assembly with the MOLEX SAS/PCIE receptacle, designed for high reliability and precision in memory card connections. This surface-mount connector features a compact 1.50mm height and is suitable for micro-SIM card applications, offering robust performance in demanding environments.
Product Features:
Part Number: 78800-0001
Manufacturer: MOLEX
Country of Origin: China (CN)
Product Category: Memory / SIM Card Connectors
Series: 78800
Connector Type: SAS/PCIE Receptacle
Mounting Style: Surface Mount (SMT)
Package: Reel (Embossed Tape)
Number of Circuits: 6
Contact Material: Copper Alloy with Gold Plating
Shell Material: Stainless Steel
Maximum Current per Contact: 0.5A
Maximum Voltage: 5V DC
Operating Temperature Range: -30°C to +85°C
Durability: Up to 5000 mating cycles
RoHS and Low-Halogen compliant
ECCN: EAR99
UOM: Each (EA)
Technical Specifications:
Physical & Electrical
Height
1.50mm
Pitch - Mating Interface
2.54mm
Card Entry Location
Top
Card Detection Switch
No
Shielded
Yes
Material - Contact
Copper Alloy
Material - Plating Mating
Gold
Material - Shell
Stainless Steel
Compliance & Certifications:
RoHS: Compliant per EU 2015/863
REACH SVHC: Not Contained per D(2024)7663-DC (21 Jan 2025)
Low-Halogen: IEC 61249-2-21 compliant
GADSL/IMDS: Compliant with Exemption 33; 34
EU RoHS Certificate: View Certificate
Additional Resources:
Disclaimer:
Datasheet was not processed please search the internet for the part number for more details.
