Best seller

Teltonika Networks

RUT300 - Industrial Ethernet Router

SKU: ELC8736

₹ 12,649.99 ~~₹ 18,499.99~~

Out of stock

Chat with us on WhatsApp We reply quickly! Contact Us

RUT300 - Industrial Ethernet Router₹ 12,649.99

Ask AI about this product

Open in ChatGPT Open in Claude Open in Gemini

Description

End of ordering: 2024 September 13

End of production: 2025 March 13

End of support: 2030 June 13

Replacement: RUT301

Standard package*

Router RUT300
9 W PSU
Ethernet cable (1.5 m)
QSG (Quick Start Guide)
Packaging box

*Standard package contents may differ based on standard order codes.

Feature

Ethernet

Category	Details
WAN	1 x WAN port 10/100 Mbps, IEEE 802.3, IEEE 802.3u, 802.3az compliant, supports auto MDI/MDIX
LAN	4 x LAN ports, 10/100 Mbps, IEEE 802.3, IEEE 802.3u, 802.3az compliant, supports auto MDI/MDIX

Network

Feature	Details
Routing	Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy-based routing
Network Protocols	TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, etc.
VoIP Passthrough	H.323 and SIP-alg protocol NAT helpers for proper VoIP packet routing
Connection Monitoring	Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP link inspection
Firewall	Port forward, traffic rules, custom rules, TTL target customisation, firewall status page
Ports Management	View, enable, disable, auto-configure, or modify transmission speed of ports
Network Topology	Visual representation of connected devices
Hotspot	Captive portal, internal/external Radius server, SMS/SSO authentication, user/group limitations, custom themes
DHCP	Static and dynamic IP allocation, DHCP relay, server configuration, static leases
QoS/SQM	Traffic prioritisation by source/destination, service, protocol, or port; WMM and 802.11e support
DDNS	Supports >25 providers, manual configuration
Network Backup	VRRP, wired options, automatic failover
Load Balancing	Distribute traffic over multiple WAN connections
SSHFS	Mount remote file systems via SSH protocol

Security

Feature	Details
Authentication	Pre-shared keys, X.509 certificates, TACACS+, Radius authentication, IP blocking, random passwords
Firewall	Preconfigured rules via WebUI, unlimited custom rules via CLI, DMZ, NAT, NAT-T, NAT64
Attack Prevention	DDOS (SYN flood, SSH, HTTP/HTTPS attack prevention), port scan protection (SYN-FIN, NULL, etc.)
VLAN	Port and tag-based VLAN separation
Web Filter	Blacklist/whitelist for website control
Access Control	SSH, Web interface, CLI, and Telnet access control
SSL Certificate Generation	Let's Encrypt and SCEP methods
802.1x	Port-based network access control

VPN

Feature	Details
OpenVPN	Multiple clients and a server can run simultaneously, 27 encryption methods
OpenVPN Encryption	DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-GCM 128, AES-256-GCM 256, etc.
IPsec	XFRM, IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES256, AES256GCM16, etc.)
GRE	GRE tunnel, GRE tunnel over IPsec support
PPTP, L2TP	Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support
Stunnel	Proxy designed to add TLS encryption functionality to existing clients and servers without changing the program’s code
DMVPN	Method of building scalable IPsec VPNs, Phase 2 and Phase 3, Dual Hub support
SSTP	SSTP client instance support
ZeroTier	ZeroTier VPN client support
WireGuard	WireGuard VPN client and server support
Tinc	Tinc offers encryption, authentication, and compression in its tunnels; Client and server support

OPC UA

Supported Modes	Details
Modes	Client, Server
Connection Types	TCP

MODBUS

Feature	Details
Supported Modes	Server, Client
Connection Types	TCP, USB
Custom Registers	MODBUS TCP custom register block requests, read/write to a file inside the router, used to extend MODBUS TCP Client functionality
Supported Data Formats	8-bit: INT, UINT; 16-bit: INT, UINT; 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII

Data to Server

Feature	Details
Protocol	HTTP(S), MQTT, Azure MQTT, Kinesis
Data to Server	Extract parameters from multiple sources and protocols, send to a single server; Custom LUA scripting enables scripts to utilize the router's Data to server feature

MQTT Gateway

Feature	Details
Modbus MQTT Gateway	Allows sending commands and receiving data from MODBUS Server through MQTT broker

DNP3

Feature	Details
Supported Modes	TCP Master, DNP3 Outstation

DLMS

Feature	Details
DLMS Support	DLMS - standard protocol for utility meter data exchange
Supported Modes	Client
Supported Connection Types	TCP
COSEM	Allows scanning meter COSEM objects for automatic detection and configuration

API

Feature	Details
Teltonika Networks Web API	Expand your device's possibilities by using configurable API endpoints to retrieve or change data.
	For more information, refer to: Teltonika API Documentation

Monitoring and Management

Category	Features
Web UI	- HTTP/HTTPS - Status and Configuration - FW (Firmware) Update - CLI - Troubleshooting - Multiple Event Log Servers - Firmware Update Notifications - Event, System, and Kernel Logs - Internet Status Monitoring
FOTA	- Firmware Update from Server - Automatic Notification for Updates
SSH	- SSH v1 and v2
TR-069	- Compatible with OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly Tech, AVSystem
MQTT	- MQTT Broker - MQTT Publisher
SNMP	- SNMP (v1, v2, v3) - SNMP Trap - Brute Force Protection
JSON-RPC	- Management API over HTTP/HTTPS
RMS	- Teltonika Remote Management System (RMS)

IoT Platforms Support

Platform	Features
Cloud of Things	- Monitoring Device Data - Mobile Data - Network Info - Availability
ThingWorx	- Monitoring WAN Type and WAN IP
Cumulocity	- Monitoring Device Model, Revision, Serial Number - WAN Type and IP - Reboot and Firmware Upgrade Actions
Azure IoT Hub	- Sends Device IP, Bytes Sent/Received, Temperature, and PIN Count to Azure IoT Hub Server

System Characteristics

Component	Details
CPU	- Qualcomm MIPS 24kc, 650 MHz
RAM	- 64 MB, DDR2
Flash Storage	- 16 MB, SPI Flash

Firmware / Configuration

Category	Features
Web UI	- Firmware Update from File - Check Firmware on Server - Configuration Profiles - Configuration Backup
FOTA	- Firmware Updates
RMS	- Updates Firmware/Configuration for Multiple Devices at Once
Keep Settings	- Update Firmware Without Losing Current Configuration
Factory Reset	- Restores All Settings to Default Manufacturer's Configuration, Including IP, PIN, and User Data

Firmware Customization

Category	Features
Operating System	- RutOS (OpenWrt-based Linux OS)
Supported Languages	- Busybox Shell - Lua - C - C++
Development Tools	- SDK Package with Build Environment Provided
GPL Customization	- Create Custom/Branded Firmware and Web Applications - Customize Colors, Logos, and UI Elements

Location Tracking

Feature	Details
NTRIP	- Supports NTRIP Protocol (Networked Transport of RTCM via Internet Protocol)

USB

Category	Features
Data Rate	- USB 2.0
Applications	- Samba Share - USB-to-Serial
External Devices	- Supports External HDD, Flash Drives, Additional Modem, Printer, USB-Serial Adapter
Storage Formats	- FAT - FAT32 - exFAT - NTFS (Read-Only) - ext2 - ext3 - ext4

Input / Output

Category	Features
Input	- 2 x Configurable Digital Inputs - 0 - 5 V detected as logic low - 8 - 30 V detected as logic high
Output	- 2 x Configurable Digital Outputs - Open Collector Output - Max Output: 30 V, 300 mA
Events	- Trigger Event via Email or RMS
I/O Juggler	- Set I/O Conditions to Initiate Specific Events

Power

Category	Details
Connector	4-pin industrial DC power socket
Input Voltage Range	7 - 30 VDC, reverse polarity protection, voltage surge/transient protection
PoE (Passive)	Passive PoE over spare pairs, powered through LAN1 port, not compatible with IEEE802.3 standards, Mode B, 9 - 30 VDC
Power Consumption	Idle: 1.3 W Max: 3 W

Physical Interfaces

Interface	Details
Ethernet	5 x RJ45 ports, 10/100 Mbps
I/Os	2 x Configurable I/O pins on 4-pin power connector
Status LEDs	5 x ETH status, 1 x Power
Power	1 x 4-pin power connector
USB	1 x USB A port for external devices
Reset	Reboot/User default reset/Factory reset button

Physical Specifications

Category	Details
Casing Material	Aluminium housing
Dimensions (W x H x D)	100 x 30 x 85 mm
Weight	229 g
Mounting Options	DIN rail, wall mount, flat surface (all require additional kit)

Operating Environment

Category	Details
Operating Temperature	-40 °C to 75 °C
Operating Humidity	10% to 90% non-condensing
Ingress Protection Rating	IP30

Regulatory & Type Approvals

Category	Details
Regulatory	CE, UKCA, UCRF, CITC, ANRT, FCC, IC, RCM, BSMI, KC, CB

EMC Emissions & Immunity

Standard	Details
General	EN 55032:2015 + A11:2020, EN 61000-3-3:2013 + A1:2019, EN IEC 61000-3-2:2019, EN 55035:2017
ESD	EN 61000-4-2:2009
Radiated Immunity	EN IEC 61000-4-3:2006 + A1:2008 + A2:2010
EFT	EN 61000-4-4:2012
Surge Immunity	EN 61000-4-5:2014 + A1:2017
CS	EN 61000-4-6:2014
DIP	EN IEC 61000-4-11:2020

Safety Standards

Standard	Details
CE	EN IEC 62368-1:2020 + A11:2020, EN IEC 62311:2020, EN 50665:2017
RCM	AS/NZS 62368.1:2022
CB	IEC 62368-1:2018

Downloads

Manual & Documentation

Links

Is this device still available to order and what happens after the end of ordering?

Ordering ends on 2024 September 13. Production ends on 2025 March 13 and support continues until 2030 June 13. The replacement is the RUT301.

What ports does the unit provide for network connections?

The unit has 1 x WAN port and 4 x LAN ports for a total of 5 RJ45 ports at 10/100 Mbps. It supports auto MDI/MDIX.

What are the main security and routing capabilities?

It supports static and dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), firewall and NAT rules, VPN options, VLAN, QoS and access control features.

What are the power size and environment specifications?

Power input is 7 to 30 VDC with reverse polarity protection and surge protection. It uses passive PoE on LAN1, and measures 100 x 30 x 85 mm with aluminium housing. Operating temp is -40 C to 75 C and IP30 rating.

How do I get firmware updates and what support is available?

End of support is 2030 June 13. Firmware updates can be obtained from the server and via the Web UI. Documentation and downloads include user manuals, datasheets and other resources.
