YIHUA-3010D 30V DC Power Supply

YIHUA 3010D III 300W/30V/10A power supply is a high quality and efficient switching power supply YIHUA 3010D-III 30V 10A 300W (third generation) is a device that will work in the workshop of any electronics in schools, as laboratory equipment and wherever it is required safe and precise DC voltage source. A very large and bright LED display (showing
the values of voltage, intensity and power) ensures operation in all lighting conditions and the exposure of all the most important operating parameters. Light and compact structure allows for easy transport. The device has been designed in a way that allows it to be operated even by novice electronics industry.

Parameters

Model Number	YHUA3010
Model Name	YIHUA 3010D-III Switching DC Power Supply Adjustable Regulated 30V 10A / 5A Single Output Digital DC Power Supply
Output Power	350W
Output Voltage	0 – 30V (Continuously Adjustable)
Output Current	Up to 10A
Input Power Supply Voltage	220V ±10% 50Hz / 110V ±10% 60Hz
Voltage Precision	<0.1% + 0.03V
Current Precision	<0.6% + 20mA
Load Regulation	<1% + 10mV
Ripple & Noise	Vrms <0.5% (10Hz – 1MHz)
Product Weight	2 KG
Product Dimensions (L × W × H)	195 × 70 × 157 mm
Colour Name	Green
Number of Pieces	1
Package Includes	1 × Power Supply, 1 × Power Cable

Highlights

Adjustable regulated DC power supply with 4-digit display and built-in short-circuit, overcurrent, and overheating protection

Power indication with compact, lightweight, and portable design; low sound wave and low noise operation

Anti low-frequency and low-noise circuit design for stable performance

Small voltage fluctuation with strong load capacity and minimal interference

High-precision 4-digit value display for accurate voltage and current readings

Supports 24 hours of continuous full-load operation

Temperature-controlled intelligent cooling fan activates automatically when internal temperature reaches a set threshold

High-quality materials with reasonable internal layout for reliable high-power output

Integrated power cord with safety ground wire and included accessories for safe and convenient use

What are the main capabilities of this power supply in terms of voltage and current

It provides an adjustable output from 0 to 30 volts with up to 10 amps of current. It includes short circuit, overcurrent, and overheating protection to ensure safe operation.

Can it operate continuously at full load

Yes, it is designed for 24 hours of continuous full load operation. A temperature controlled cooling fan activates automatically when needed.

What safety features are included

It has built in short circuit, overcurrent, and overheating protections. The unit uses anti low frequency and low noise circuit design for stable performance.

How easy is it to monitor the output values

A large bright LED display shows voltage, current and power with a 4 digit readout for precise measurements.

What is included with the package and what input voltages are supported

The package includes the power supply and a power cable. It supports 220V 50 Hz and 110V 60 Hz input with a safety grounded power cord.
